1.5W/MK White Thermal Conductive Silicone Pad 3.0mmT For GPS Navigation Device

1.5W/MK White Thermal Conductive Silicone Pad 3.0mmT For GPS Navigation Device

  • 1.5W/MK White Thermal Conductive Silicone Pad 3.0mmT For GPS Navigation Device
  • 1.5W/MK White Thermal Conductive Silicone Pad 3.0mmT For GPS Navigation Device
  • 1.5W/MK White Thermal Conductive Silicone Pad 3.0mmT For GPS Navigation Device
1.5W/MK White Thermal Conductive Silicone Pad 3.0mmT For GPS Navigation Device
Product Details:
Place of Origin: China
Brand Name: Ziitek
Certification: UL & RoHS
Model Number: TIF1120-06E Series
Payment & Shipping Terms:
Minimum Order Quantity: 1000pcs
Price: 0.1-10 USD/PCS
Packaging Details: 24*23*12cm cantons
Delivery Time: 3-5 work days
Payment Terms: T/T
Supply Ability: 1000000 pcs/month
Contact Now
Detailed Product Description
Thickness: 3.0mmT Specific Gravity: 2.15 G/cc
Dielectric Breakdown Voltage: >5000 VAC Thermal Conductivity: 1.5W/m-K
Color: White
High Light:

Thermal Conductive Silicone Pad 3.0mmT

,

White Thermal Conductive Silicone Pad

,

GPS Navigation Device Silicone Thermal Pad

-40 to 160℃ White thermal conductive silicone pad For GPS navigation and other portable devices 1.5W/m-K


The TIF1120-06E Series is a silicone based, thermally conductive gap pad. Its unreinforced construction allows additional compliancy. This product has low hardness is conformable and is electrically isolating. The low modulus characteristic of the product offers optimal thermal performance with the ease of handling


Features
> Good thermal conductive: 1.5W/mK
> Available in varies thickness
> UL recognized
> Broad range of hardnesses available
> High tack surface reduces contact resistance

> Electrically isolating


Applications
LED TV / LED Lit Lamps
> CD-Rom, DVD-Rom cooling
> SAD-DC Power Adapters
> CPU
> Memory Modules
routers
Telecommunication hardware

> mainboard/mother board

> IT infrastructure

> GPS navigation and other portable devices



TIF100-06E Series Datasheet-(E)-REV01.pdf




                                            Typical Properties of TIF1120-06E Series

Color
White
Visual
Composite Thickness
Thermal Impedance @10psi
(℃-in²/W)
Construction &
Compostion
Ceramic filled silicone elastomer
***
10mils / 0.254 mm
0.16
20mils / 0.508 mm
0.20
Specific Gravity
2.15 g/cc
ASTM D297
30mils / 0.762 mm
0.31
40mils / 1.016 mm
0.36
Thickness range 0.010"-0.200"
ASTM C351
50mils / 1.270 mm
0.42
60mils / 1.524 mm
0.48
Hardness
35Shore 00
ASTM 2240
70mils / 1.778 mm
0.53
80mils / 2.032 mm
0.63
Dielectric Breakdown Voltage



>5000 VAC
ASTM D412
90mils / 2.286 mm
0.73
100mils / 2.540 mm
0.81
Continuos Use Temp



-40 to 160℃
***
110mils / 2.794 mm
0.86
120mils / 3.048 mm
0.93
Outgassing(TML)
0.55%
ASTM E595
130mils / 3.302mm
1.00
140mils /3.556 mm
1.08
Dielectric Constant
5.5 MHz
ASTM D150
150mils / 3.810 mm
1.13
160mils / 4.064 mm
1.20



Volume Resistivity
4.0X10"
Ohm-meter
ASTM D257
170mils / 4.318 mm
1.24
180mils / 4.572 mm
1.32
Fire rating
94 V0
equivalent
UL
190mils / 4.826 mm
1.41
200mils / 5.080 mm
1.52
Thermal conductivity
1.5W/m-K
ASTM D5470
Visua l/ ASTM D751
ASTM D5470



Standard Sheets Sizes:

8" x 16"(203mm x 406mm)

16" x 18"(406mm x 457mm)



TIF™ series Individual die cut shapes can be supplied.



Packaging Details & Lead time



The packaging of thermal pad

1.with PET film or foam-for protection

2. use Paper Card To Separate Each Layer

3. export carton inside and outside

4. meet with customers' requirement-customized



Lead Time :Quantity(Pieces):5000

Est. Time(days): To be negotiated



1.5W/MK White Thermal Conductive Silicone Pad 3.0mmT For GPS Navigation Device 0



Ziitek has independent R&D team. This team is experience, rigorous and pragmatic.

They undertake the core research and development tasks of Ziitek thermal conductive materials. With well-equipped testing equipment, we Ziitek can also do some tests with customers' samples, so we can find a more suitable Ziitek materials for every customer.
