| Place of Origin: | China |
| Brand Name: | Ziitek |
| Certification: | UL |
| Model Number: | TIF1140-01US thermal pad |
| Minimum Order Quantity: | 1000 pcs |
|---|---|
| Price: | 0.1-10 USD/PCS |
| Packaging Details: | 25*24*13cm canton |
| Delivery Time: | 3-8 work days |
| Payment Terms: | T/T |
| Supply Ability: | 100000pcs/month |
| Thickness: | 3.5mmT | Volume Resistivity: | 1.0*1012 Ohm-cm |
|---|---|---|---|
| Name: | Dielectric Breakdown Voltage >5500 VAC Silicone Pads Low Cost For Automotive Electronics | Keyword: | Thermal Gap Pad |
| Hardness: | 20 Shore 00 | Dielectric Breakdown Voltage: | >5500 VAC |
| High Light: | 3.5mmt silicone thermal pad,automotive electronics silicone thermal pad,3.5mmt thermal conductive silicone pad |
||
Dielectric Breakdown Voltage >5500 VAC silicone pads low cost for Automotive electronics
Company Profile
With professional R&D capabilities and over 17 year experiences in thermal interface material industry, Ziitek company own many unique formulations which are our core technologies and advantages. Our goal is to provide quality & competitive products to our customers worldwide aiming for long-term business cooperation.
TIF100-01US-Series-Datasheet.pdf
<Electrically isolating
High durability
Good thermal conductive
<Automotive electronics
<Set top boxes
<Audio and video components
<IT infrastructure
<GPS navigation and other portable devices
<CD-Rom, DVD-Rom cooling
|
Typical Properties of TIFTIF1140-01US
|
|||
|
Product Name
|
TIF1140-01US Series |
||
|
Colour
|
Black | ||
|
Construction & Compostion
|
Ceramic filled silicone elastomer
|
||
|
Specific gravity |
1.9 g/cc
|
||
|
Thickness |
3.5mmT
|
||
|
Hardness
|
20 Shore 00
|
||
|
Dielectric constant@1MHz
|
2.9 MHz
|
||
|
Continuos Use Temp
|
-40 to 160℃
|
||
|
Dielectric Breakdown Voltage |
>5500 VAC
|
||
|
Thermal conductivity
|
1.5 W/mK
|
||
| Volume Resistivity |
1.0*1012 Ohm-cm |
||
Standard Thicknesses:
0.020" (0.51mm) 0.030" (0.76mm)
0.040" (1.02mm) 0.050" (1.27mm) 0.060" (1.52mm)
0.070" (1.78mm) 0.080" (2.03mm) 0.090" (2.29mm)
0.100" (2.54mm) 0.110" (2.79mm) 0.120" (3.05mm)
0.130" (3.30mm) 0.140" (3.56mm) 0.150" (3.81mm)
0.160" (4.06mm) 0.170" (4.32mm) 0.180" (4.57mm)
0.190" (4.83mm) 0.200" (5.08mm)
Consult the factory to alternate thickness.
Our services
Online-service : 12 hours , Inquiry reply within fastest.
Working time: 8:00am - 5:30pm, Monday to Saturday (UTC+8).
Well-trained & experienced staff are to answer all your inquiries in English of course.
Standard Export Carton Or Marked With Customer's Information Or Customized.
Provide free samples
After-service: Even our products have passed strict inspection, if you find the parts can not work well, please show us the proof.
we will help you to deal with it and give you satisfactory solution.
