Name: Low-Melting Thermal Interface Material Phase Change Sheet For Power Conversion Equipment
Brand: Dongguan Ziitek Electronical Material and Technology Ltd.
SKU: TIC800H
Price: 4.10 USD
Availability: InStock

Home Products PCM Phase Change Material

Low-Melting Thermal Interface Material Phase Change Sheet For Power Conversion Equipment

Product Details:

Place of Origin:	China
Brand Name:	Ziitek
Certification:	RoHS
Model Number:	TIC800H

Payment & Shipping Terms:

Minimum Order Quantity:	1000pcs
Price:	0.1-10 USD/PCS
Packaging Details:	241312cm cartons
Delivery Time:	3-6 work days
Payment Terms:	T/T
Supply Ability:	1000000 pcs/month

Contact Now

Detailed Product Description

Name:	Low-Melting Thermal Interface Material Phase Change Sheet For Power Conversion Equipment	Applicatoin:	Power Conversion Equipment
Recommended Operating Temp(℃）:	-40~125℃	Color:	Gray
Keyword:	Phase Change Materials	Feature:	Low Thermal Resistant
Phase Change Softening Temperature:	50~60℃	Thermal Conductivity:	7.5W/mK
Highlight:	Low-Melting Thermal Interface Material , Power Conversion Equipment Thermal Interface Material , Thermal Interface Material Phase Change Sheet

Low-Melting Thermal Interface Material Phase Change Sheet For Power Conversion Equipment

Ziitek Electronic Material and Technology Ltd. is a R&D and production company, we have many production lines and processing technology of thermal conductive materials, owns advanced production equipment and optimized process, can provide various thermal solutions for different applications.

TIC^®800H Series is a high-performance, cost-effective thermal interface material featuringa unique grain-oriented structure that enables precise conformity to device surfaces,thereby enhancing the thermal conduction path and transfer efficiency. When the temperature exceeds its phase transition point of 50°℃, the material softens and undergoes phase change,effectively filling microscopic and uneven gaps between components to form a low thermal resistance interface,significantly improving heat dissipation performance.

Features
> Low thermal resistance
> Self-adhesive with no need for additional surface adhesives
> Low-pressure application environment

Applications
> Power conversion equipment

> Power supply and vehicle storage battery
> Large communication switch hardware

> LED TV, Lighting
> Laptop computer

Typical Properties of TIC^®800H Series
Product Name	TIC^®808H	TIC^®810H	TIC^®812H	Test Method
Color	Gray			Visual
Thickness	0.008"	0.010"	0.012"	ASTM D374
Thickness	(0.200mm)	(0.250mm)	(0.300mm)	ASTM D374
Density	2.7g/cc			ASTM D792
Recommended Operating Temperature (℃)	-40℃～125℃			Ziitek Test Method
Phase Change Softening Temperature(℃)	50℃~60℃			Ziitek Test Method
Thermal Conductivity	7.5 W/mK			ASTM D5470
Thermal Impedance(℃-cm²/W) @10 psi	0.018	0.019	0.021	ASTM D5470
Thermal Impedance(℃-cm²/W) @50 psi	0.013	0.014	0.015	ASTM D5470

Standard Thickness:0.008(0.20 mm),0.010(0.25 mm),0.012"(0.30 mm).

For other thickness options, please contact us.

Standard Size: 10”x 16"(254 mm x 406 mm).
Pressure-Sensitive Adhesive: lt is not applicable to TIC^®800H series products.Reinforcement Material: No reinforcementmaterial required.

Low-Melting Thermal Interface Material Phase Change Sheet For Power Conversion Equipment 0

Our services

Online-service : 12 hours , Inquiry reply within fastest.

Working time: 8:00am - 5:30pm, Monday to Saturday (UTC+8).

Well-trained & experienced staff are to answer all your inquiries in English of course.

Standard Export Carton Or Marked With Customer's Information Or Customized.

Provide free samples

After-service: Even our products have passed strict inspection, if you find the parts can not work well, please show us the proof.

we will help you to deal with it and give you satisfactory solution.
