Costomized Thermally Conductive Electrical Insulator Sheet Thermal Interface Materials
Ziitek company is a high-tech enterprise which dedicated to the R&D, manufacture and sales of the thermal interface materials (TIMs). We have rich experiences in this field which can support you the latest, most effective and one -step thermal management solutions. We have many advanced production equipments,full test equipments and fully automatic coating production lines which can support the production for high performance thermal silicone pad, thermal graphite sheet/ film, thermal double-sided tape, thermal insulation pad, thermal ceramic pad, phase change material, thermal grease etc. UL94 V-0, SGS and ROHS are compliant.
TIS100-02 Series Datasheet-(E)-REV01 (1).pdf
The TIS™100-02 Series products are the high-efficiency insulation ones with thermal conduction properties. The supplement of the insulation base film made by silicagel into the heat-conduction material creates a great effecton both the insulation and heat conduction.
Features
> Moldability for complex parts
> Highly compliant surface characteristic with high thermal conductivity
> High thermal conductive and High dielectric strength
> Low thermal resistance with high voltage isolation
> Resistant to tears and punctures
Applications
> Power conversion equipment
>LED TV and LED-lit lamps
> Power semiconductors:To packages, MOSFETs & IGBTs
> Audio and Video components
> Automotive control units
> Motor controllers
> General high pressure interface
| Typical Properties of TIS100-02 series |
| Product Name |
TIS109-02 |
TIS112-02 |
TIS118-02 |
Test Method |
| Color |
Pink |
Visual |
| Construction &Compostion |
Ceramic filled silicone elastomer / Fiberglass |
******* |
| Composite Thickness |
0.23mm |
0.3mm |
0.45mm |
ASTM D374 |
| Hardness |
50 Shore A |
ASTM D751 |
| Specific Gravity |
1.751g/cc |
ASTM D297 |
| Tensile Strength |
425 Kpsi |
ASTM D412 |
| Continuous Use Temp |
-45 to 180℃ |
******* |
| Dielectric Breakdown Voltage |
>3500 VAC |
ASTM D149 |
| Dielectric Constant |
5.5 MHz |
ASTM D150 |
| Volume Resistivity |
4.0X10¹³ Ohm-meter |
ASTM D257 |
| Flame Rating |
94 V0 |
E331100 |
| Thermal conductivity |
1.0 W/mK |
ASTM D5470 |
Standard Thicknesses:
0.005"(0.127mm) 0.006"(0.152mm) 0.008"(0.203mm) 0.009"(0.228mm)
0.010"(0.254mm) 0.012"(0.304mm) 0.018"(0.457mm)
Consult the factory alternate thickness.
Standard Sizes:
16" x 18"(406mm x 457mm) 16" x 200'(406mm x 60.9M)
Individual die cut shapes can be supplied.
Peressure Sensitive Adhesive:
Request adhesive on one side with "A1" suffix.
Request adhesive on doule side with "A2" suffix.
Reinforcement:
TIS™ series sheets are fiberglass reinforced.
Ziitek Culture
Quality :
Do it right the first time, total quality control
Effectiveness:
Work precisely and thoroughly for effectiveness
Service:
Quick response, On time delivery and Excellent service
Team work:
Complete teamwork, including sales team, Marketing team, engineering team, R&D team, Manufacturing team, logistics team. All is for supporting and servicing a satisfy service for customers.
Packaging Details & Lead time
The packaging of thermal pad
1.with PET film or foam-for protection
2. use Paper Card To Separate Each Layer
3. export carton inside and outside
4. meet with customers' requirement-customized
Lead Time :Quantity(Pieces):5000
Est. Time(days): To be negotiated
FAQ:
Q: Are you trading company or manufacturer ?
A: We are manufacturer in China.
Q: How long is your delivery time?
A: Generally it is 3-7 work days if the goods are in stock. or it is 7-10 work days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra cost?
A: Yes, we could offer samples free of charge.
