Name: Low Thermal Resistance 0.229mm Thermal Insulation Materail For Car Battery & Power Supply
Brand: Dongguan Ziitek Electronical Material and Technology Ltd.
SKU: TIS809-16-02
Price: 4.10 USD
Availability: InStock

Home Products Thermally Conductive Electrical Insulator

Low Thermal Resistance 0.229mm Thermal Insulation Materail For Car Battery & Power Supply

Product Details:

Place of Origin:	China
Brand Name:	Ziitek
Certification:	UL & RoHS
Model Number:	TIS809-16-02

Payment & Shipping Terms:

Minimum Order Quantity:	1000pcs
Price:	0.1-10 USD/pcs
Packaging Details:	241312cm cartons
Delivery Time:	3-6 work days
Supply Ability:	1000000 pcs/month

Contact Now

Detailed Product Description

Product Name:	Low Thermal Resistance 0.229mm Thermal Insulation Materail For Car Battery & Power Supply	Thickness Range(inch/mm):	0.012/0.305
Color:	Pink	Materials:	Ceramic Filled Silicone Elastomer / Polyimide Film
Feature:	Low Thermal Resistant With High Voltage Isolation	Thermal Conductive:	1.6W/mK
Continous Use Temp:	-60 To 180℃	Compliance:	UL & RoHS
Application:	Car Battery & Power Supply	Keyword:	Thermal Insulation Materail

Low Thermal Resistance 0.229mm Thermal Insulation Materail For Car Battery & Power Supply

With professional R&D capabilities and many year experiences in thermal interface material industry, Ziitek company own many unique formulations which are our core technologies and advantages. Our goal is to provide quality & competitive products to our customers worldwide aiming for long-term business cooperation.

The TIS^®809-16-02 Series of products are highly efficient insulating products and they also have thermal conductivity. It achieves the effect of both insulation and heat conduction by adding insulating silicone base material to the heat-conducting material.

Features:
> High thermal conductive and High dielectric strength
> Low thermal resistance with high voltage isolation
> Resistant to tears and punctures

> RoHS compliant
> UL recognized

Applications:
> Car Battery & Power Supply

> Power semiconductors
> Audio and Video components

> Motor controllers

> Heat pipe thermal solutions
> Memory Modules
> CPU
> Display card
> Mainboard/mother board
> Notebook
> Power supply

> Medical Devices
> Auditioning electronic products
> unmanned aerial vehicle(UAV)

Typical Properties of TIS^®809-16-02 Series
Property	Value	Test Method
Color	Pink	Visual
Construction &Compostion	Ceramic filled silicone elastomer /Polyimide film	******
Thickness range	0.009inch (0.229mm)	ASTM D374
Tensile Strength(MPa)	9.0	ASTM D412
Density	2.4 g/cc	ASTM D297
Continuos Use Temp	-60 to 180℃	******
Breakdown Voltage(V/mm)	5500	ASTM D149
Dielectric Constant @ 1MHz	6.0	ASTM D150
Volume Resistivity	1.0X10¹²Ohm-meter	ASTM D257
Fire rating	94 V0	UL94(E331100)
Thermal conductivity	1.6W/m-K	ASTM D5470
Thermal impedance(℃-in²/W)@30psi	0.65	ASTM D5470

Standard Thicknesses

0.009inch (0.229mm)

Standard Sizes
12" x 160"(304mm * 48.76M)

The TlS series can be die-cut into different shapes and provided. lf you need different thicknesses, please contact our company.

Low Thermal Resistance 0.229mm Thermal Insulation Materail For Car Battery & Power Supply 0

Packaging Details & Lead time

1.with PET film or foam-for protection

2. use Paper Card To Separate Each Layer

3. export carton inside and outside

4. meet with customers' requirement-customized

Lead Time :Quantity(Pieces):5000

Est. Time(days): To be negotiated

Why Choose us ?

1.Our value message is'' Do it right the First time, total quality control''.

2.Our core competencies is thermal conductive interface materials.

3.Competitive advantage products.

4.Condidentiality agreement Bussiness Secrect Contract.

5.Free sample offer.

6.Quality assurance contract.
