Name: RoHS Compliant Electrical Insulation 1.5W/MK Ultra Soft Thermal Gap Pad For LED Power Supply
Brand: Dongguan Ziitek Electronical Material and Technology Ltd.
SKU: TIF120-01E Series
Price: 4.10 USD
Availability: InStock

Home Products Silicone Thermal Pad

RoHS Compliant Electrical Insulation 1.5W/MK Ultra Soft Thermal Gap Pad For LED Power Supply

Product Details:

Place of Origin:	China
Brand Name:	Ziitek
Certification:	UL & RoHS
Model Number:	TIF120-01E Series

Payment & Shipping Terms:

Minimum Order Quantity:	1000pcs
Price:	0.1-10 USD/PCS
Packaging Details:	241312cm cartons
Delivery Time:	3-5 work days
Payment Terms:	T/T
Supply Ability:	1000000 pcs/month

Contact Now

Detailed Product Description

Products Name:	RoHS Compliant Electrical Insulation 1.5W/MK Ultra Soft Thermal Gap Pad For LED Power Supply	Thickness:	0.5-5.0mmT
Specific Gravity:	2.3 G/cc	Dielectric Breakdown Voltage:	>5500 VAC
Thermal Conductivity:	1.5W/m-K	Keywords:	Ultra Soft Thermal Gap Pad
Application:	LED Power Supply
Highlight:	Thermal Gap Filler Pad 0.5mmT , 1.5W/MK Thermal Gap Filler Pad , 94 V0 thermally conductive silicone sheet

RoHS Compliant Electrical Insulation 1.5W/MK Ultra Soft Thermal Gap Pad For LED Power Supply

Company Profile

With a wide range, good quality, reasonable prices and stylish designs, Ziitek thermal conductive interface materials are extensively used in Mainboards, VGA cards, Notebooks, DDR&DDR2 products, CD-ROM ,LCD TV, PDP products, Server Power products, Down lamps, Spotlights, Street lamps, Daylight lamps, LED Server Power products and others.

Certifications:

ISO9001:2015

ISO14001: 2004 IATF16949:2016

IECQ QC 080000:2017

The TIF120-01E Series thermal silicone pad is a product with both performance and economy. It is a unique thermal pad with low oil permeability, low thermal resistance, high softness and high compliance.It can work stably at -40℃~160℃ and meet the requirement of UL94V0.

TIF100-01E Datasheet-REV02.pdf

Features

> Good thermal conductive: 1.5W/mK
> Available in varies thickness
> UL recognized
> Broad range of hardnesses available
> High tack surface reduces contact resistance

Applications

> LED TV / LED Lit Lamps
> CD-Rom, DVD-Rom cooling
> SAD-DC Power Adapters
> CPU
> Memory Modules
> routers
> Telecommunication hardware

Typical Properties of TIF120-01E Series
Color	Black	Visual
Construction & Compostion	Ceramic filled silicone elastomer	***

Specific Gravity	2.3 g/cc	ASTM D297

Thickness range	0.020"-0.200"	ASTM C351

Hardness	35 Shore 00	ASTM 2240

Dielectric Breakdown Voltage	>5500 VAC	ASTM D412

Continuos Use Temp	-40 to 160℃	***

Outgassing(TML)	0.35%	ASTM E595

Dielectric Constant	4.7MHz	ASTM D150

Volume Resistivity	1.0X10¹²Ohm-meter	ASTM D257

Fire rating	94 V0	equivalent UL

Thermal conductivity	1.5W/m-K	ASTM D5470

Peressure Sensitive Adhesive:

Request adhesive on one side with "A1" suffix.

Request adhesive on double side with "A2" suffix.

Reinforcement: TIF™ series sheets type can add with fiberglass reinforced.

RoHS Compliant Electrical Insulation 1.5W/MK Ultra Soft Thermal Gap Pad For LED Power Supply 0

Why Choose us ?

1.Our value message is'' Do it right the First time, total quality control''.

2.Our core competencies is thermal conductive interface materials

3.Competitive advantage products.

4.Condidentiality agreement Bussiness Secrect Contract

5.Free sample offer

6.Quality assurance contract

Ziitek Culture

Quality :

Do it right the first time, total quality control

Effectiveness:

Work precisely and thoroughly for effectiveness

Service:

Quick response, On time delivery and Excellent service

Team work:

Complete teamwork, including sales team, Marketing team, engineering team, R&D team, Manufacturing team, logistics team. All is for supporting and servicing a satisfy service for customers.

Tag:
