Dielectric Constant 5.0 Mhz Silicone Thermal Pad For Led Panellight

Dielectric Constant 5.0 Mhz Silicone Thermal Pad For Led Panellight

Dielectric Constant 5.0 Mhz Silicone Thermal Pad For Led Panellight
video
Dielectric Constant 5.0 Mhz Silicone Thermal Pad For Led Panellight
Product Details:
Place of Origin: China
Brand Name: Ziitek
Certification: UL
Model Number: TIF140-30-06UF thermal pad
Payment & Shipping Terms:
Minimum Order Quantity: 1000 pcs
Price: 0.1-10 USD/PCS
Packaging Details: 25*24*13cm canton
Delivery Time: 3-8 work days
Payment Terms: T/T
Supply Ability: 100000pcs/month
Contact Now
Detailed Product Description
Keyword: Thermal Gap Pad Hardness: 75±5 Shore 00
Name: Dielectric Constant 5.0 MHz Silicone Pads Easy Release Construction For LED PanelLight Dielectric Constant: 5.0 MHz
Specific Gravity: 3.0 G/cc Color: White
High Light:

5.0 mhz silicone thermal pad

,

led panellight silicone thermal pad

,

5.0 mhz thermal conductive silicone pad

Dielectric constant 5.0 MHz silicone pads Easy release construction for LED PanelLight



Company Profile With professional R&D capabilities and over 17 year experiences in thermal interface material industry, Ziitek company own many unique formulations which are our core technologies and advantages. Our goal is to provide quality & competitive products to our customers worldwide aiming for long-term business cooperation.



TIF100-30-06UF-Series-Datasheet-.pdf



Ziitek TIF140-30-06UF thermal silicone pad is a product with both performance and economy. It is a unique thermal pad with low oil permeability, low thermal resistance, high softness and high compliance.It can work stably at -40℃~160℃ and meet the requirement of UL94V0.




<Good thermal conductive:3.0 W/mK
<Thickness: 1.0mmT
<Hardness:75±5 Shore 00
<Colour: White

<Available in varies thicknesses
<Broad range of hardnesses available
<Moldability for complex parts




Applications

<Waterproof LED Power
<SMD LED module
<LED Flesible strip, LED bar
<LED PanelLight
<LED floor light
<Routers



Typical Properties of TIF140-30-06UF

Product Name

TIF140-30-06UF Series

Colour
White
Construction & Compostion
Ceramic filled silicone elastomer

Specific gravity

3.0 g/cc

Thickness

1.0mmT
Hardness
75±5 Shore 00
Dielectric constant@1MHz
5.0 MHz
Continuos Use Temp
-40 to 160℃

Dielectric Breakdown Voltage

>5500 VAC
Thermal conductivity
3.0 W/mK
Volume Resistivity

2.3*1013 Ohm-cm



Standard Sheets Sizes:
8" x 16"(203mm x 406mm)

TIF™ series Individual die cut shapes can be supplied.


Dielectric Constant 5.0 Mhz Silicone Thermal Pad For Led Panellight 0





Why Choose us ?

1.Our value message is'' Do it right the First time, total quality control''.
2.Our core competencies is thermal conductive interface materials
3.Competitive advantage products.
4.Condidentiality agreement Bussiness Secrect Contract
5.Free sample offer
6.Quality assurance contract



Dielectric Constant 5.0 Mhz Silicone Thermal Pad For Led Panellight 1

FAQ


Q:How can we get detailed price list?
A:Please offer us detailed information of the product such as Size(length,width,thickness),color,specific packaging requirements and purchasing quantity.
Q: What kind of packaging you offer?

A: During the packaging process, preventive measures will be taken by us to assure that the goods are in a good condition during storage and delivery.
