Name: Durable Silicone Thermal Conductive Cooling Insulator Pad For Laptop CPU Gap Filling Materials With Fiberglass
Brand: Dongguan Ziitek Electronical Material and Technology Ltd.
SKU: TIS809-09-01
Price: 4.10 USD
Availability: InStock

Home Products Thermally Conductive Electrical Insulator

Durable Silicone Thermal Conductive Cooling Insulator Pad For Laptop CPU Gap Filling Materials With Fiberglass

Product Details:

Place of Origin:	China
Brand Name:	Ziitek
Certification:	UL & RoHS
Model Number:	TIS809-09-01

Payment & Shipping Terms:

Minimum Order Quantity:	1000pcs
Price:	0.1-10 USD/pcs
Packaging Details:	241312cm cartons
Delivery Time:	3-6 work days

Contact Now

Detailed Product Description

Product Name:	Durable Silicone Thermal Conductive Cooling Insulator Pad For Laptop CPU Gap Filling Materials With Fiberglass	Thermal Conductive:	0.9W/mK
Application:	Car Battery & Laptop CPU	Continous Use Temp:	-60 To 180℃
Compliance:	UL & RoHS	Materials:	Ceramic Filled Silicone Elastomer / Fiberglass
Feature:	Low Thermal Resistant With High Voltage Isolation	Keyword:	Thermal Insulator Pad

Durable Silicone Thermal Conductive Cooling Insulator Pad For Laptop CPU Gap Filling Materials With Fiberglass

With professional R&D capabilities and many year experiences in thermal interface material industry, Ziitek company own many unique formulations which are our core technologies and advantages. Our goal is to provide quality & competitive products to our customers worldwide aiming for long-term business cooperation.

The TIS^®809-09-01 Series of products are highly efficient insulating products and they alsohave thermal conductivity. It achieves the effect of both insulation and heat conduction byadding insulating silicone base material to the heat-conducting material.

Features:
> High thermal conductive and High dielectric strength
> Low thermal resistance with high voltage isolation
> Resistant to tears and punctures

Applications:
> Car Battery & Power Supply

> Power semiconductors
> Audio and Video components

> Motor controllers

Typical Properties of TIS^®809-09-01 Series
Property	Value	Test Method
Color	Gray	Visual
Construction &Compostion	Ceramic filled silicone elastomer /fiberglass	******
Thickness range	0.009inch (0.229mm)	ASTM D374
Tensile Strength(MPa)	50	ASTM D412
Density	2.4 g/cc	ASTM D297
Continuos Use Temp	-60 to 180℃	******
Breakdown Voltage(V/mm)	4500	ASTM D149
Dielectric Constant @ 1MHz	5.5	ASTM D150
Volume Resistivity	1.0X10¹² Ohm-meter	ASTM D257
Fire rating	94 V0	equivalent UL
Thermal conductivity	0.9W/m-K	ASTM D5470
Thermal impedance(℃-in²/W)@30psi	1.73	ASTM D5470

Standard Thicknesses

0.009inch (0.229mm)

Standard Sizes
12" x 160"(304mm x 48.76M)

The TlS series can be die-cut into different shapes and provided. lf you need different thicknesses, please contact our company.

Durable Silicone Thermal Conductive Cooling Insulator Pad For Laptop CPU Gap Filling Materials With Fiberglass 0

Packaging Details & Lead time

1.with PET film or foam-for protection

2. use Paper Card To Separate Each Layer

3. export carton inside and outside

4. meet with customers' requirement-customized

Lead Time :Quantity(Pieces):5000

Est. Time(days): To be negotiated

Why Choose us ?

1.Our value message is'' Do it right the First time, total quality control''.

2.Our core competencies is thermal conductive interface materials.

3.Competitive advantage products.

4.Condidentiality agreement Bussiness Secrect Contract.

5.Free sample offer.

6.Quality assurance contract.
