Name: Thermal Silicone Insulation Pad For Gpu Cpu Cooling Pad 0.305MM Low Thermal Resistance
Brand: Dongguan Ziitek Electronical Material and Technology Ltd.
SKU: TIS812-11-03
Price: 4.10 USD
Availability: InStock

Home Products Thermally Conductive Electrical Insulator

Thermal Silicone Insulation Pad For Gpu Cpu Cooling Pad 0.305MM Low Thermal Resistance

Product Details:

Place of Origin:	China
Brand Name:	Ziitek
Certification:	UL & RoHS
Model Number:	TIS812-11-03

Payment & Shipping Terms:

Minimum Order Quantity:	1000pcs
Price:	0.1-10 USD/pcs
Packaging Details:	241312cm cartons
Delivery Time:	3-6 work days
Supply Ability:	1000000 pcs/month

Contact Now

Detailed Product Description

Product Name:	Thermal Silicone Insulation Pad For Gpu Cpu Cooling Pad 0.305MM Low Thermal Resistance	Thickness Range(inch/mm):	0.012/0.305
Color:	Yellow	Materials:	Ceramic Filled Silicone Elastomer / Polyimide Film
Feature:	Low Thermal Resistant With High Voltage Isolation	Thermal Conductive:	1.2W/mK
Continous Use Temp:	-60 To 180℃	Compliance:	UL & RoHS
Application:	GPU Cpu Battery	Keyword:	Thermal Silicone Insulation Pad

Thermal Silicone Insulation Pad For Gpu Cpu Cooling Pad 0.305MM Low Thermal Resistance

Ziitek Electronic Material and Technology Ltd. is dedicated to developing composite thermal solution and manufacturing superior thermal interface materials for competitive market. Our vast experience allows us to assist our customers best in thermal engineering field.We serve customers with customized products, full product lines and flexible production, which makes us be the best and reliable partner of you. Let's make your design more perfect!

The TIS^®812-11-03 Series of products are highly efficient insulating products and they also have thermal conductivity. It achieves the effect of both insulation and heat conduction by adding insulating silicone base material to the heat-conducting material.

Features:
> High thermal conductive and High dielectric strength
> Low thermal resistance with high voltage isolation
> Resistant to tears and punctures

> Easy release construction
> Electrically isolating
> High durability

Applications:
> Car Battery & Power Supply

> Power semiconductors
> Audio and Video components

> Motor controllers

> Heat pipe thermal solutions
> Memory Modules
> CPU
> Display card
> Mainboard/mother board
> Notebook
> Power supply

Typical Properties of TIS^®812-11-03 Series
Property	Value	Test Method
Color	Yellow	Visual
Construction &Compostion	Ceramic filled silicone elastomer /Polyimide film	******
Thickness range	0.012inch (0.305mm)	ASTM D374
Tensile Strength(MPa)	1.5	ASTM D412
Density	2.4 g/cc	ASTM D297
Continuos Use Temp	-60 to 180℃	******
Breakdown Voltage(V/mm)	5000	ASTM D149
Dielectric Constant @ 1MHz	5.0	ASTM D150
Volume Resistivity	1.0X10¹²Ohm-meter	ASTM D257
Fire rating	94 V0	UL94(E331100)
Thermal conductivity	1.1W/m-K	ASTM D5470
Thermal impedance(℃-in²/W)@30psi	0.61	ASTM D5470

Standard Thicknesses

0.012inch (0.305mm)

Standard Sizes
12" x 160"(304mm * 48.76M)

The TlS series can be die-cut into different shapes and provided. lf you need different thicknesses, please contact our company.

Thermal Silicone Insulation Pad For Gpu Cpu Cooling Pad 0.305MM Low Thermal Resistance 0

Packaging Details & Lead time

1.with PET film or foam-for protection

2. use Paper Card To Separate Each Layer

3. export carton inside and outside

4. meet with customers' requirement-customized

Lead Time :Quantity(Pieces):5000

Est. Time(days): To be negotiated

Our services

Online-service : 12 hours , Inquiry reply within fastest.

Working time: 8:00am - 5:30pm, Monday to Saturday (UTC+8).

Well-trained & experienced staff are to answer all your inquiries in English of course.

Standard Export Carton Or Marked With Customer's Information Or Customized.

Provide free samples

After-service: Even our products have passed strict inspection, if you find the parts can not work well, please show us the proof.

we will help you to deal with it and give you satisfactory solution.
