Name: UL Recognized Premium Soft Thermal Conductivity 1.5W/MK Silicone Thermal Pad For Unmanned Aerial Vehicle(UAV)
Brand: Dongguan Ziitek Electronical Material and Technology Ltd.
SKU: TIF100-01S Series
Price: 4.10 USD
Availability: InStock

Home Products Silicone Thermal Pad

UL Recognized Premium Soft Thermal Conductivity 1.5W/MK Silicone Thermal Pad For Unmanned Aerial Vehicle(UAV)

Product Details:

Place of Origin:	China
Brand Name:	Ziitek
Certification:	UL & RoHS
Model Number:	TIF100-01S Series

Payment & Shipping Terms:

Minimum Order Quantity:	1000pcs
Price:	0.1-10 USD/PCS
Packaging Details:	241312cm cartons
Delivery Time:	3-5 work days
Payment Terms:	T/T
Supply Ability:	1000000 pcs/month

Contact Now

Detailed Product Description

Products Name:	UL Recognized Premium Soft Thermal Conductivity 1.5W/MK Silicone Thermal Pad For Unmanned Aerial Vehicle(UAV)	Thermal Conductivity:	1.5W/m-K
Thickness Range:	0.020"(0.5mm)~0.200"(5.0mm)	Color:	Black
Dielectric Constant:	4.5 MHz	Application:	Unmanned Aerial Vehicle(UAV)
Dielectric Breakdown Voltage:	>5500 VAC	Fire Rating:	94 V0
Keywords:	Silicone Thermal Pad

UL Recognized Premium Soft Thermal Conductivity 1.5W/MK Silicone Thermal Pad For Unmanned Aerial Vehicle(UAV)

Company Profile

Ziitek Electronic Material and Technology Ltd. is dedicated to developing composite thermal solution and manufacturing superior thermal interface materials for competitive market. Our vast experience allows us to assist our customers best in thermal engineering field.We serve customers with customized products, full product lines and flexible production, which makes us be the best and reliable partner of you. Let's make your design more perfect!

Certifications:

ISO9001:2015

ISO14001: 2004 IATF16949:2016

IECQ QC 080000:2017

The TIF^®100-01S is not only designed to take advantage of the gap heat transfer, to fill gaps, complete the heat transfer between heating and cooling parts, but also played insulation, damping, sealing and so on, to meet the equipment miniaturization and ultra-thin design Requirements, which is a highly technology and use, and the thickness of the wide range of applications, is also an excellent thermal conductivity filler material.

Features

> Good thermal conductive: 1.5W/mK

> Naturally tacky needing no further adhesive coating
> Available in varies thicknesses
> High tack surface reduces contact resistance
> RoHS compliant
> UL recognized

Applications

> LED TV / LED Lit Lamps
> Automotive engine control units
> SAD-DC Power Adapters
> Handheld portable electronics
> Semiconductor automated test equipment (ATE)

> Micro heat pipe thermal solutions
> Memory Modules

> Routers

> Telecommunication hardware

> Mainboard/mother board

> CPU
> Display card
> Routers
> Medical Devices
> Auditioning electronic products
> unmanned aerial vehicle(UAV)

Typical Properties of TIF^®100-01S Series
Property	Value	Test method
Color	Black	Visual
Construction & Compostion	Ceramic filled silicone elastomer	******
Thickness range	0.020"(0.5mm)~0.200"(5.0mm)	ASTM D374
Specific Gravity	2.3 g/cc	ASTM D792
Hardness	45 Shore 00	ASTM 2240
Operating Temp	-45 ~ 200℃	******
Dielectric Breakdown Voltage	≥5500 VAC	ASTM D149
Dielectric Constant @1MHz	4.5 MHz	ASTM D150
Volume Resistivity	≥1.0X10¹²Ohm-cm	ASTM D257
Fire rating	94 V0	UL E331100
Outgassing(TML)	0.35%	ASTM E595
Thermal conductivity	1.5W/m-K	ASTM D5470

Product Thicknesses: 0.020"(0.5mm)~0.200"(5.0mm)

Product Sizes: 8" x 16"(203mm x406mm)

Individual die cut shapes and custom thickness can be supplied. Please contact us for confirming
Safe disposal method does not require special protection.The storage condition is low temperature anddry, away from open fire and away from direct sunlight. For detailed method, please refer to the product material safety data sheet.

Packaging Details & Lead time

The packaging of thermal pad

1.with PET film or foam-for protection

2. use Paper Card To Separate Each Layer

3. export carton inside and outside

4. meet with customers' requirement-customized

Lead Time :Quantity(Pieces):5000

Est. Time(days): To be negotiated
