Name: Black Thermal Conductive Nylon 5.0W Plastic Material For Cooling For Molding And Plastic Parts
Brand: Dongguan Ziitek Electronical Material and Technology Ltd.
SKU: TCP200-50-02A
Price: 55.00 USD
Availability: InStock

Home Products Heat Conductive Plastic

Black Thermal Conductive Nylon 5.0W Plastic Material For Cooling For Molding And Plastic Parts

Product Details:

Place of Origin:	China
Brand Name:	Ziitek
Certification:	RoHS
Model Number:	TCP200-50-02A

Payment & Shipping Terms:

Minimum Order Quantity:	25kg
Price:	USD 10-100/BAG
Packaging Details:	25kg/bag
Delivery Time:	3-7 work days
Payment Terms:	T/T
Supply Ability:	1000bag/month

Contact Now

Detailed Product Description

Products Name:	Black Thermal Conductive Nylon 5.0W Plastic Material For Cooling For Molding And Plastic Parts	Color:	Black
Specific Gravity:	1.45g/cc	Thermal Conductivity Through Plane:	5.0W/mK
Heat Deflection Temperature:	150℃	Keywords:	Thermal Nylon Plastic Material
Material:	Nylon
Highlight:	high thermal conductivity plastic , conductive thermoplastic , Heat Deflection Rainproof Relay Sealant

Black Thermal Conductive Nylon 5.0W Plastic Material For Cooling For Molding And Plastic Parts

TCP^TM200-50-02A is a Thermally Conductive EngineeringPlastic developed for the housing design which requires highthermally conductivity and reduces the weight more than 30%comparing with the same aluminium devices.

Application
TCP™100-25-06A can be used in applications such as Heat Sinking Housing at LED-lit BLU in LCD/LED TV and LED-lit lamps such as MR16. Also it can replace the normal Aluminum heat sink.

Black Thermal Conductive Nylon 5.0W Plastic Material For Cooling For Molding And Plastic Parts 0

Feature
>Good thermal conductivity: 5.0W/mK

>Excellent thermal conductivity compared to normal engineering plastics
>Lighter than normal Aluminum housing 30% in weight
>Excellent mould ability in injection moulding

>Much higher production yield than normal

Typical Properties of TCP^TM200-50-02A
Items	Test method	Unit	Typical data
Physical Properties
Material	*****	*****	Nylon
Color	Visual	*****	black
Melt index	ASTM D1238	g/10min	4
Specific Gravity	ASTM D792	g/cm3	1.45
Shrinkage	ASTM D955	%	0.3-0.5
Mechanical Properties
Tensile Strength	ASTM D638	MPa	55
Flexural Strength	ASTM D790	MPa	80
Flexural Modulus	ASTM D638	MPa	15800
Impact Strength, notched	ASTM D256	kJ/㎡	2.5~3.5
Electrical Properties
Dielectric Constant, 1MHz	ASTM D150	*****	4.5
Volume Resistivity	ASTM D257	Ohm-meter	10000
Thermal Properties
Heat Deflection Temperature	ASTM D648	℃	150
Vicat Temperature	ASTM D648	℃	15.0
Thermal Conductivity Throngh Plane	ASTM E1461	W/m-K	5.0
Flame retardancy	Min. thick. 1.0mm	Class	V-0

Black Thermal Conductive Nylon 5.0W Plastic Material For Cooling For Molding And Plastic Parts 1

Company profile

Ziitek Electronic Material and Technology Ltd. is dedicated to developing composite thermal solution and manufacturing superior thermal interface materials for competitive market. Our vast experience allows us to assist our customers best in thermal engineering field.We serve customers with customized products, full product lines and flexible production, which makes us be the best and reliable partner of you. Let's make your design more perfect!

FAQ:

Q: Are you trading company or manufacturer ?

A: We are manufacturer in China.

Q: How long is your delivery time?

A: Generally it is 3-7 work days if the goods are in stock. or it is 7-10 work days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra cost?

A: Yes, we could offer samples free of charg.

Q: How do I request customized samples?

A: To request samples, you can leave us message on website, or just contact us by send email or call us.
