Ultra Soft Thermal Conductive Gap Filler 20shore00 3.5mmT For IT Infrastructure

Ultra Soft Thermal Conductive Gap Filler 20shore00 3.5mmT For IT Infrastructure

Ultra Soft Thermal Conductive Gap Filler 20shore00 3.5mmT For IT Infrastructure
video
Ultra Soft Thermal Conductive Gap Filler 20shore00 3.5mmT For IT Infrastructure
Product Details:
Place of Origin: China
Brand Name: Ziitek
Certification: UL
Model Number: TIF5140-50-11US thermal pad
Payment & Shipping Terms:
Minimum Order Quantity: 1000 pcs
Price: 0.1-10 USD/PCS
Packaging Details: 25*24*13cm canton
Delivery Time: 3-8 work days
Payment Terms: T/T
Supply Ability: 100000pcs/month
Contact Now
Detailed Product Description
Hardness: 20shore00 KEYWORD: Grey Silicone Rubber Pads
Color: Grey Part Number: TIF5140-50-11US
Material: Silicone Thermal Conductive: 5.0W/m-k
High Light:

3.5mmT Thermal Conductive Gap Filler

,

20shore00 Thermal Conductive Gap Filler

,

IT Infrastructure conductive gap filler

3.5mmT Manufactured Thermal Conductive Gap Filler,Ultra Soft 20shore00 For IT Infrastructure

3.5mmT manufactured thermal conductive gap filler, ultra soft 20shore00 For IT infrastructure



Ziitek TIF5140-50-11US is not only designed to take advantage of the gap heat transfer, to fill gaps, complete the heat transfer between heating and cooling parts, but also played insulation, damping, sealing and so on, to meet the equipment miniaturization and ultra-thin design Requirements, which is a highly technology and use, and the thickness of the wide range of applications, is also an excellent thermal conductivity filler material.



TIF500-50-11US Datasheet-REV02.pdf



Company Profile

Ziitek Electronic Material and Technology Ltd. is dedicated to developing composite thermal solution and manufacturing superior thermal interface materials for competitive market.

Our vast experience allows us to assist our customers best in thermal engineering field.

We serve customers with customized products, full product lines and flexible production, which makes us be the best and reliable partner of you. Let's make your design more perfect!


Features

<Good thermal conductive:5.0W/m-k

<Thickness:3.5mmT

<High durability

<High tack surface reduces contact resistance

<Moldability for complex parts



Applications

<IT infrastructure

<GPS navigation and other portable devices

<notebook

<power supply

<LED Controller

<LED Ceilinglamp

<Monitoring the Power Box




Typical Properties of TIF 5140-50-11US

Product Name
TIF5140-50-11US Series
Colour
Grey
Construction & Compostion
Ceramic filled silicone rubber
Specific Gravity
3.0g/cc
Dielectric Constant@1MHz
4.0 MHz
Hardness
20 Shore 00
Flame Rating
94 -V0
Continuos Use Temp
-40to 160℃
Dielectric Breakdown Voltage
>5500 VAC
Thermal conductivity
5.0 W/mK
Thickness
3.5mmT



Peressure Sensitive Adhesive:

Request adhesive on one side with "A1" suffix.

Request adhesive on double side with "A2" suffix.



Reinforcement: TIF™ series sheets type can add with fiberglass reinforced.





Packaging Details & Lead time



The packaging of thermal pad

1.with PET film or foam-for protection

2. use Paper Card To Separate Each Layer

3. export carton inside and outside

4. meet with customers' requirement-customized



Lead Time :Quantity(Pieces):5000

Est. Time(days): To be negotiated


Ultra Soft Thermal Conductive Gap Filler 20shore00 3.5mmT For IT Infrastructure 0

Advantage



Ziitek has independent R&D team. This team is experience, rigorous and pragmatic.

They undertake the core research and development tasks of Ziitek thermal conductive materials. With well-equipped testing equipment, we Ziitek can also do some tests with customers' samples, so we can find a more suitable Ziitek materials for every customer.
