| Place of Origin: | China |
| Brand Name: | Ziitek |
| Certification: | UL |
| Model Number: | TIF5100S thermal pad |
| Minimum Order Quantity: | 1000 pcs |
|---|---|
| Price: | 0.1-10 USD/PCS |
| Packaging Details: | 25*24*13cm canton |
| Delivery Time: | 3-8 work days |
| Payment Terms: | T/T |
| Supply Ability: | 100000pcs/month |
| Hardness: | 45shore00 | KEYWORD: | Blue Silicone Rubber Pads |
|---|---|---|---|
| Color: | Blue | Part Number: | TIF5100S |
| Material: | Silicone | Thickness: | 2.5mmT |
| High Light: | Silicone Sheet 2.5mmT,Silicone Sheet Electrically Isolating,2.5mmT Silicone Rubber Pads |
||
High Cost-Effectiv Silicone Sheet 2.5mmT 3.2W/M-K Electrically Isolating For Micro Heat Pipe Thermal Solutions
high cost-effectiv silicone sheet 2.5mmT 3.2W/M-K electrically isolating For Micro heat pipe thermal solutions
Company Profile
Ziitek company is a high-tech enterprise which dedicated to the R&D, manufacture and sales of the thermal interface materials (TIMs). We have rich experiences in this field which can support you the latest, most effective and one -step thermal management solutions. We have many advanced production equipments,full test equipments and fully automatic coating production lines which can support the production for high performance thermal silicone pad, thermal graphite sheet/ film, thermal double-sided tape, thermal insulation pad, thermal ceramic pad, phase change material, thermal grease etc. UL94 V-0, SGS and ROHS are compliant.
<Soft and compressible for low stress applications
<Naturally tacky needing no further adhesive coating
<High tack surface reduces contact resistance
<Easy release construction
<Micro heat pipe thermal solutions
<Automotive engine control units
<CD-Rom, DVD-Rom cooling
<LED Power Supply
<LED Controller
<LED Ceilinglamp
|
Typical Properties of TIF 5100S
|
|||
|
Product Name
|
TIF5100S Series
|
||
|
Colour
|
Blue | ||
|
Construction & Compostion
|
Ceramic filled silicone rubber
|
||
|
Specific Gravity
|
3.0g/cc
|
||
|
Thickness |
2.5mmT
|
||
|
Hardness
|
45 Shore 00
|
||
|
Tensile Strength
|
40 psi
|
||
|
Continuos Use Temp
|
-40to 160℃
|
||
|
Dielectric Breakdown Voltage
|
>5500 VAC
|
||
|
Thermal conductivity
|
3.2 W/mK
|
||
Advantage
With professional R&D capabilities and over 13 year experiences in thermal interface material industry, Ziitek company own many unique formulations which are our core technologies and advantages. Our goal is to provide quality & competitive products to our customers worldwide aiming for long-term business cooperation.
Packaging Details & Lead time
The packaging of thermal pad
1.with PET film or foam-for protection
2. use Paper Card To Separate Each Layer
3. export carton inside and outside
4. meet with customers' requirement-customized
Lead Time :Quantity(Pieces):5000
Est. Time(days): To be negotiated
