Name: Thermal Gap Filler For Automotive Electronics 1.8W/MK Thickness 2.5mmT
Brand: Dongguan Ziitek Electronical Material and Technology Ltd.
SKU: TIF1100-18-01US thermal pad
Price: 4.10 USD
Availability: InStock

Home Products CPU Thermal Pad

Thermal Gap Filler For Automotive Electronics 1.8W/MK Thickness 2.5mmT

Product Details:

Place of Origin:	China
Brand Name:	Ziitek
Certification:	UL
Model Number:	TIF1100-18-01US thermal pad

Payment & Shipping Terms:

Minimum Order Quantity:	1000 pcs
Price:	0.1-10 USD/PCS
Packaging Details:	252413cm canton
Delivery Time:	3-8 work days
Payment Terms:	T/T
Supply Ability:	100000pcs/month

Contact Now

Detailed Product Description

Hardness:	18 Shore00	KEYWORD:	Black Silicone Rubber Pads
Color:	Black	Part Number:	TIF1100-18-01US
Material:	Silicone
Highlight:	1.8W/MK Thermal Gap Filler , Automotive Electronics Thermal Gap Filler , 2.5mmT Thermal Gap Filler

Factory supply low cost thermal conductive gap filler,2.0mmT 1.8W/mK for micro heat pipe thermal solutions

Company Profile

With professional R&D capabilities and over 13 year experiences in thermal interface material industry, Ziitek company own many unique formulations which are our core technologies and advantages. Our goal is to provide quality & competitive products to our customers worldwide aiming for long-term business cooperation.

TIF100-18-01US-Specification-sheet.pdf

TIF1100-18-01US is an extremely soft gap filling material rated at a thermal conductivity of 1.8W/m-K. It is specially formulated for high performance applications requiring low assembly stress. The material offers exceptional thermal performance at low pressures due to the unique filler package and ultra low modulus resin formulation. TIF1100-18-01US is highly conformal to rough or irregular surfaces, allowing excellent wet-out at the interface. Protective liners are supplied on both sides allowing for ease of use.

Features

<Good thermal conductive:1.8W/mK

<Thickness:2.5mmT

<Hardness:18 Shore 00

<Colour: black

<Outstanding thermal performance

<Easy release construction

<Moldability for complex parts

Applications

<power supply

<Heat pipe thermal solutions

<LED Power Supply

<LED Controller

<AD-DC Power Adapters

<Rainproof LED Power

Typical Properties of TIF1100-18-01US
Product Name	TIF1100-18-01US Series
Colour	black
Construction & Compostion	Ceramic filled silicone elastomer
Specific gravity	2.5 g/cc
Thickness	2.5mmT
Hardness	18 Shore 00
Dielectric constant@1MHz	4.5 MHz
Continuos Use Temp	-40to 160℃
Dielectric Breakdown Voltage	>5500 VAC
Thermal conductivity	1.8 W/mK
Volume Resistiviyt	1.0*10^12 _Ohm-cm

Peressure Sensitive Adhesive:

Request adhesive on one side with "A1" suffix.

Request adhesive on double side with "A2" suffix.

Reinforcement: TIF™ series sheets type can add with fiberglass reinforced.

FAQ

Q: How do I request customized samples?

A: To request samples, you can leave us message on website, or just contact us by send email or call us.

Q: Do you accept custom orders ?

A:Yes , welcome to custom orders. Our custom elements including dimension , shape , color and coated on side or two sides adhesive or coated fiberglass. If you want to place a custom order , pls kindly offer a drawing or leave your custom order information .
