1.5mmT Heat Sink Thermal Pad Silicone Based 0.5mm Thickness Thermal Interface Material For Thermal Management Of LED TV Components

1.5mmT Heat Sink Thermal Pad Silicone Based 0.5mm Thickness Thermal Interface Material For Thermal Management Of LED TV Components

Product Details:
Place of Origin: China
Brand Name: Ziitek
Certification: UL
Model Number: TIF160-20-10UF thermal pad
Document: TIF100-20-10UF_Data Sheet.pdf
Payment & Shipping Terms:
Minimum Order Quantity: 1000 pcs
Price: 0.1-10 USD/PCS
Packaging Details: 24*13*12cm carton
Delivery Time: 3-8 work days
Payment Terms: T/T
Supply Ability: 100000pcs/month
Contact Now
Detailed Product Description
Products Name: 1.5mmT Heat Sink Thermal Pad Silicone Based 0.5mm Thickness Thermal Interface Material For Thermal Management Of LED TV Components Composition: Ceramic Filled Silicone Elastomer
Keyword: Heat Sink Thermal Pad Recommended Operating Temperatuer: -40 To 200℃
Thickness: 1.5mmT Feature: Moldability For Complex Parts
Thermal Conductivity: 2.0W/m·K Application: LED TV Components
Highlight:

1.5mmT Thermal Conductive Pads Heatsink

,

Silicone Thermal Conductive Pads Heatsink

,

1.5mmT Thermal Pad For Heat Sink

Product Overview

TIF®160-20-10UF Series is a structurally supportive thermal pad designed to provide good heat dissipation while also ensuring structural support and durability. It reliably fills interface gaps, transfers heat, and offers mechanical support for stacked components, resisting compressive deformation. This product is an ideal choice for applications that require a balance between heat dissipation, insulation, and mechanical stability.

Key Features
  • Good thermal conductivity: 2.0 W/mK
  • Thickness: 1.5mmT
  • Hardness: 75 Shore 00
  • Moldability for complex parts
  • Soft and compressible for low-stress applications
  • Naturally tacky, requiring no additional adhesive coating
  • High-tack surface reduces contact resistance
Applications
  • Automotive electronics
  • Cooling components to the chassis or frame
  • High-speed mass storage drives
  • Heat sinking housing at LED-lit BLU in LCD
  • LED TV and LED-lit lamps
  • Handheld portable electronics
Typical Properties of TIF®100-20-10UF Series
Property Value Test Method
Color Gray Visual
Composition Ceramic filled silicone elastomer ZKTM J024
Density (g/cm³) 2.8 ASTM D792
Thickness Range (inch/mm) 0.010~0.200 / 0.25~5.00 ASTM D374
Hardness (Shore 00) 75 ASTM 2240
Recommended Operating Temperature -40 to 200°C ZKTM J025
Breakdown Strength (V/mm) ≥5500 ASTM D149
Dielectric Constant @1MHz 6.5 ASTM D150
Volume Resistivity (Ohm-cm) >1.0×10¹² ASTM D257
Flame Rating V-0 UL 94 (E331100)
Thermal Conductivity (W/m-K) 2.0 ASTM D5470
Thermal Conductivity (W/m-K) 2.0 ISO22007
Company Profile

Ziitek is a high-tech enterprise dedicated to the R&D, manufacture, and sales of thermal interface materials (TIMs). With rich experience in this field, we support customers with the latest, most effective, and one-step thermal management solutions. We operate many advanced production equipments, full test equipments, and fully automatic coating production lines, enabling the production of high-performance thermal silicone pads, thermal graphite sheets/films, thermal double-sided tape, thermal insulation pads, thermal ceramic pads, phase change materials, thermal grease, and more. Our products are UL94 V-0, SGS, and RoHS compliant.

Ziitek thermal interface material production facility and product display
Ziitek Culture
Quality

Do it right the first time, total quality control.

Effectiveness

Work precisely and thoroughly for effectiveness.

Service

Quick response, on-time delivery, and excellent service.

Teamwork

Complete teamwork across sales, marketing, engineering, R&D, manufacturing, and logistics teams — all working together to deliver satisfying service for customers.

Ziitek team collaboration and company culture
Frequently Asked Questions

Q: Are you a trading company or a manufacturer?

A: We are a manufacturer in China and Vietnam.

Q: How long is your delivery time?

A: Generally 3–7 working days if the goods are in stock, or 7–10 working days if the goods are not in stock, depending on quantity.

Q: What is a Thermal Interface Material (TIM)?

A: Thermal Interface Materials (TIMs) are used to fill microscopic air gaps between a heat source and a heat sink, reducing interface thermal resistance and improving heat transfer efficiency. Common TIMs include thermal pads, thermal gels, thermal greases, and phase-change materials.

Q: What is thermal conductivity? Is higher thermal conductivity always better?

A: Thermal conductivity measures a material's ability to conduct heat and is typically expressed in W/m·K. Higher thermal conductivity generally indicates better heat conduction, but actual thermal performance also depends on thickness, interface resistance, compression, and contact area.

Q: What is thermal resistance in thermal interface materials?

A: Thermal resistance represents the resistance to heat flow through a material or interface. For TIM applications, actual thermal resistance can be more meaningful than thermal conductivity alone.

Q: What is the difference between thermal conductivity and thermal resistance?

A: Thermal conductivity describes the intrinsic heat-conduction capability of a material, while thermal resistance also depends on thickness, contact area, and interface conditions.

Q: Does higher thermal conductivity always mean better cooling?

A: Not necessarily. Thickness, interface contact, compression, and actual thermal resistance can significantly affect final cooling performance.
