Name: 5.0W Gray Thermal Interface Silicone Thermal Pad With Flame Retardant Properties For Automotive And Industrial Electronics
Brand: Dongguan Ziitek Electronical Material and Technology Ltd.
SKU: TIF800 Series
Price: 4.10 USD
Availability: InStock

Home Products Silicone Thermal Pad

5.0W Gray Thermal Interface Silicone Thermal Pad With Flame Retardant Properties For Automotive And Industrial Electronics

Product Details:

Place of Origin:	China
Brand Name:	Ziitek
Certification:	UL & RoHS
Model Number:	TIF800 Series
Document:	TIF800_Data Sheet.pdf

Payment & Shipping Terms:

Minimum Order Quantity:	1000pcs
Price:	0.1-10 USD/PCS
Packaging Details:	241312cm cartons
Delivery Time:	3-5 work days
Payment Terms:	T/T
Supply Ability:	1000000 pcs/month

Contact Now

Detailed Product Description

Products Name:	5.0W Gray Thermal Interface Silicone Thermal Pad With Flame Retardant Properties For Automotive And Industrial Electronics	Application:	Automotive And Industrial Electronics
Feature:	Soft And Naturally Tacky Needing No Further Adhesive Coating	Hardness:	45/65 Shore 00
Thickness Range(inch/mm):	0.010"~0.200"(0.25~5.00mm)	Keywords:	Silicone Thermal Pad
Thermal Conductive:	5.0W/mK
Highlight:	heat conductive pad , thermal cooling pad , 0.25mm Silicone Thermal Pad

5.0W Gray Thermal Interface Silicone Thermal Pad With Flame Retardant Properties For Automotive And Industrial Electronics

Company Profile

Ziitek Electronic Material and Technology Ltd. is dedicated to developing composite thermal solution and manufacturing superior thermal interface materials for competitive market. Our vast experience allows us to assist our customers best in thermal engineering field.We serve customers with customized products, full product lines and flexible production, which makes us be the best and reliable partner of you. Let's make your design more perfect.

The TIF^®800 Series use a special process, with silicone as the base material, adding thermal conductive powder and flame retardant together to make the mixture to become thermal interface material. This is effective in lower the thermal resistance between the heat source and the heat sink.

Features

> RoHS compliant
> UL recognized
> Good thermal conductive: 5.0 W/mK
>Naturally tacky needing no further adhesive coating
> Outstanding thermal performance
> Electrically isolating
> High durability

> Soft and compressible for low stress

Applications

> CPU
> Cooling components to the chassis of frame
> High speed mass storage drives
> GPS navigation and other portable devices
> LED TV and LED-lit lamps
> RDRAM memory modules
> Display card
> Mainboard/mother board
> Notebook
> Power supply
> Heat pipe thermal solutions
> Memory Modules

Typical Properties of TIF^®800 Series
Property	Value		Test method
Color	Gray		Visual
Construction & Compostion	Ceramic filled silicone elastomer		******
Density(g/cm³)	3.35		ASTM D792
Thickness Range(inch/mm)	0.010~0.020	0.030~0.200	ASTM D374
	0.25~0.50	0.75~5.00
Hardness (Shore 00)	65	45	ASTM 2240
Recommended Operating Temperature (℃)	-40 to 200		******
Breakdown Voltage (V/mm)	≥5500		ASTM D149
Dielectric Constant @ 1MHz	6.0		ASTM D150
Volume Resistivity (Ohm-meter)	＞1.0X10¹²		ASTM D257
Flame rating	V-0		UL 94 (E331100)
Thermal conductivity	5.0W/m-K		ASTM D5470
	5.0W/m-K		ISO22007

Product Specifications
Standard Thickness: 0.010" (0.25 mm)~0.200" (5.00 mm) with increments of 0.010" (0.25 mm)
Standard Size: 16"X16" (406 mm×406 mm)

Component Codes:
Reinforcement Fabric: FG (Fiberglass).
Coating Options: NS1 (Non-adhesive treatment), DC1 (Single-sided hardening).
Adhesive Options: A1/A2 (Single-sided/Double-sided adhesive).

The TIF^® series is availablein custom shapes and various forms.
For other thicknesses or more information, please contact us.

5.0W Gray Thermal Interface Silicone Thermal Pad With Flame Retardant Properties For Automotive And Industrial Electronics

Packaging Details & Lead time

The packaging of thermal pad

1.with PET film or foam-for protection

2. use Paper Card To Separate Each Layer

3. export carton inside and outside

4. meet with customers' requirement-customized

Lead Time :Quantity(Pieces):5000

Est. Time(days): To be negotiated
