Heat Sink Thermal Pad Featuring High Tack Surface And 3.5mm Thickness For Optimal Thermal Management In Mainboard/mother Board

Heat Sink Thermal Pad Featuring High Tack Surface And 3.5mm Thickness For Optimal Thermal Management In Mainboard/mother Board

Product Details:
Place of Origin: China
Brand Name: Ziitek
Certification: UL
Model Number: TIF1140-20-10UF thermal pad
Document: TIF100-20-10UF_Data Sheet.pdf
Payment & Shipping Terms:
Minimum Order Quantity: 1000 pcs
Price: 0.1-10 USD/PCS
Packaging Details: 24*13*12cm carton
Delivery Time: 3-8 work days
Payment Terms: T/T
Supply Ability: 100000pcs/month
Contact Now
Detailed Product Description
Products Name: Heat Sink Thermal Pad Featuring High Tack Surface And 3.5mm Thickness For Optimal Thermal Management In Mainboard/mother Board Breakdown Strength(V/mm): ≥5500
Thickness: 3.5mmT Certification: ISO9001
Keyword: Thermal Pad Recommended Operating Temperature: -40 To 200℃
Thermal Conductivity(W/m·K): 2.0 Application: Mainboard/mother Board
Hardness(shore Oo): 75
Highlight:

3.5mm Heat Sink Thermal Pad

,

LED TV Heat Sink Thermal Pad

,

3.5mm Thermal Pad For Heat Sink

Product Overview

The TIF®1140-20-10UF Series is a structurally supportive thermal pad designed to deliver reliable heat dissipation while ensuring mechanical support and durability. It effectively fills interface gaps, transfers heat, and provides mechanical support for stacked components, resisting compressive deformation. This product is an ideal choice for applications requiring a balance between heat dissipation, insulation, and mechanical stability.

Key Features
  • Good thermal conductivity
  • Good softness and fillability
  • Self-adhesive without the need for additional surface adhesives
  • Good insulation performance
Applications
  • Cooling components to the chassis or frame
  • High-speed mass storage drives
  • Heat sinking housing at LED-lit BLU in LCD
  • LED TV and LED-lit lamps
  • RDRAM memory modules
  • Micro heat pipe thermal solutions
Typical Properties of TIF®100-20-10UF Series
Property Value Test Method
Color Gray Visual
Construction & Composition Ceramic filled silicone elastomer ZKTM J024
Density (g/cm³) 2.8 ASTM D792
Thickness Range (inch/mm) 0.010~0.200 / 0.25~5.00 ASTM D374
Hardness (Shore OO) 75 ASTM 2240
Recommended Operating Temperature -40 to 200°C ZKTM J025
Breakdown Strength (V/mm) ≥5500 ASTM D149
Dielectric Constant @1MHz 6.5 ASTM D150
Volume Resistivity (Ohm-cm) >1.0×10¹² ASTM D257
Flame Rating V-0 UL 94 (E331100)
Thermal Conductivity (W/m-K) 2.0 ASTM D5470
Thermal Conductivity (W/m-K) 2.0 ISO 22007
Company Profile

Ziitek, founded in 2006 and headquartered in Dongguan, Guangdong Province, is a high-tech enterprise focusing on heat conduction, heating, sealing, and EMI. The company operates production bases in Kunshan, Taiwan Province, and Vietnam, with a global layout ensuring efficient delivery. Adhering to the concept of "resource sharing and joint development," Ziitek discusses future technology and application design requirements with customers from the research and development stage, providing solutions ranging from thermal interface materials to EMI shielding, heating products, seals, and thermal engineering plastics. The products have passed certifications including IATF16949 and ISO9001, and meet ROHS, REACH, and UL specifications, helping customers create greater value in fields such as new energy, AI, 5G, and aerospace.

Ziitek company facility and thermal management product showcase
Ziitek Culture
Quality

Do it right the first time, total quality control.

Effectiveness

Work precisely and thoroughly for effectiveness.

Service

Quick response, on-time delivery, and excellent service.

Teamwork

Complete teamwork, including sales, marketing, engineering, R&D, manufacturing, and logistics teams. All is for supporting and servicing a satisfying experience for customers.

Ziitek team collaboration and thermal management solutions
Frequently Asked Questions
Q: How do I request customized samples?

A: To request samples, you can leave us a message on our website, or simply contact us by email or phone.

Q: What is the thermal conductivity test method given on the data sheet?

A: All data in the sheet are actual tested results. Hot Disk and ASTM D5470 are utilized to test thermal conductivity.

Q: What is a Thermal Silicone Pad?

A: A thermal silicone pad is a pre-formed TIM typically made of a silicone-based material and thermally conductive fillers. It is designed to fill gaps between heat sources and heat sinks. Depending on the product formulation, thermal silicone pads can also provide electrical insulation.

Q: What are the advantages of Thermal Silicone Pads?

A: Key advantages include easy installation, controlled thickness, good flexibility, and effective gap-filling capability. Depending on the application, thermal silicone pads can also be designed with different levels of thermal conductivity, hardness, flame resistance, and electrical insulation.

Q: Is a thinner Thermal Silicone Pad always better?

A: Not necessarily. If the pad is too thin to adequately fill the actual gap, proper interface contact may not be achieved. The appropriate thickness should be selected based on the actual structural tolerances and application requirements.

Ratings & Review

Overall Rating

5.0
Based on 50 reviews for this supplier

Rating Snapshot

The following is the distribution of all ratings
5 stars
100%
4 stars
0%
3 stars
0%
2 stars
0%
1 stars
0%

All Reviews

J
Jesus
Vietnam Jul 8.2026
if you are plannig to replace old pads from a laptop get the dimension of the old ones so you cut the same size. I got twenty of this to be safe. Best results if you cut it with a blade.
