GPU CPU Heatsink Cooling Conductive Silicone Pad Thermal Pad

Product Details:

Place of Origin:	China
Brand Name:	Ziitek
Certification:	UL
Model Number:	TIF7120PES thermal pad

Payment & Shipping Terms:

Minimum Order Quantity:	1000 pcs
Price:	0.1-10 USD/PCS
Packaging Details:	252413cm canton
Delivery Time:	3-8 work days
Payment Terms:	T/T
Supply Ability:	100000pcs/month

Contact Now

Detailed Product Description

Part Number:	TIF7120PES	Name:	GPU CPU Heatsink Cooling Conductive Silicone Pad Thermal Pad
Specific Gravity:	3.2 G/cm³	Hardness:	10
Thickness:	3.0mmT	Keyword:	Thermal Pad
Highlight:	Conductive Silicone Thermal Pad , CPU Heatsink Cooling Conductive Silicone Pad , GPU Heatsink Thermal Pad

GPU CPU Heatsink Cooling Conductive Silicone Pad Thermal Pad

Company Profile

Ziitek company is a manufacturer of thermal conductive gap fillers, low melting point thermal interface materials, thermal conductive insulators, thermally conductive tapes, electrically & thermally conductive Interface pads and thermal grease,Thermal Conductive plastic,Silicone Rubber,Silicone Foams,Phase Changing Materials products, with well-equipped testing equipment and strong technical force.

TIF700PES-(TDS-EN-REV04).pdf

GPU CPU Heatsink Cooling Conductive Silicone Pad Thermal Pad 0

Ziitek TIF7120PES is an extremely soft gap filling material rated at a thermal conductivity of 7.5W/m-K. It is specially formulated for high performance applications requiring low assembly stress. The material offers exceptional thermal performance at low pressures due to the unique filler package and ultra low modulus resin formulation. Ziitek TIF7120PES is highly conformal to rough or irregular surfaces, allowing excellent wet-out at the interface. Protective liners are supplied on both sides allowing for ease of use.

< Good thermal

< Hardness: 10

< Colour: gray

< Moldability for complex parts
< Soft and compressible for low stress applications
< Naturally tacky needing no further adhesive coating

Applications

> LED TV and LED-lit lamps
> RDRAM memory modules
> Micro heat pipe thermal solutions
> Automotive engine control units
> Telecommunication hardware
> Handheld portable electronics

Typical Properties of TIF7120PES
Product Name	TIF7120PES Series
Colour	Gray
Construction & Compostion	Ceramic filled silicone elastomer
Specific gravity	3.2 g/cc
Thickness	3.0mmT
Hardness(Shore 00)	10
Dielectric constant@1MHz	5~6 MHz
Continuos Use Temp	-40 to 160℃
Dielectric Breakdown Voltage	>5000 VAC
Thermal conductivity	7.5W/mK
Flame Rating(no.E331100)	V-0

Packaging Details & Lead time

The packaging of thermal pad

1.with PET film or foam-for protection

2. use Paper Card To Separate Each Layer

3. export carton inside and outside

4. meet with customers' requirement-customized

Lead Time :Quantity(Pieces):5000

Est. Time(days): To be negotiated

Independent R&D team

Q: How do I place an order?

A:1. Click the "Sent messages" button to continue with the process.

2. Fill out the message form by entering a subject line, and message to us.

This message should include any questions you might have about the products as well as your purchase requests.

3. Click the "Send" button when you are finished to complete the process and send your message to us

4. We will reply you as soon as possible with Email or online

FAQ

Q: Are you trading company or manufacturer ?

A: We are manufacturer in China.

Q: Do you offer free samples ?

A: Yes, we are willing to offer free sample.

Q: What is your terms of payment ?

A: Payment<=2000USD, T/T in advance. Paying in time and faithful for several months, we can apply other payment term for you, pay together in every month or 30 days.
