Name: White Heat Conductive Plastic 1.8W Lighter Than Normal Aluminum Housing For LED Light Housing
Brand: Dongguan Ziitek Electronical Material and Technology Ltd.
SKU: TCP200-18-06A
Price: 4.10 USD
Availability: InStock

Home Products Heat Conductive Plastic

White Heat Conductive Plastic 1.8W Lighter Than Normal Aluminum Housing For LED Light Housing

Product Details:

Place of Origin:	China
Brand Name:	Ziitek
Certification:	RoHS
Model Number:	TCP200-18-06A

Payment & Shipping Terms:

Minimum Order Quantity:	10kg
Price:	USD 0.1-10/kg
Packaging Details:	25kg/bag
Delivery Time:	3-5 work days
Payment Terms:	T/T
Supply Ability:	1000000pcs/month

Contact Now

Detailed Product Description

Products Name:	Lighter Than Normal Aluminum Housing White Heat Conductive Plastic 1.8W For LED Light Housing	Keyword:	Heat Conductive Plastic
Application:	LED Light Housing	Feature:	Lighter Than Normal Aluminum Housing
Specific Gravity:	1.45 G/cm3	Heat Deflection Temperature:	180℃
Thermal Conductivity:	1.8W/m-K
Highlight:	1.8W Heat Conductive Plastic , LED Light Housing Heat Conductive Plastic , White Heat Conductive Plastic

Lighter Than Normal Aluminum Housing White Heat Conductive Plastic 1.8W For LED Light Housing

TCP^TM200-18-06A is a Thermally Conductive Engineering Plastic developed for the housing design which requires high thermally conductivity and reduces the weight more than 30% comparing with the same aluminium devices.

TCP200-18-06A-Thermally-Conductive-plastic.pdf

White Heat Conductive Plastic 1.8W Lighter Than Normal Aluminum Housing For LED Light Housing 0

Application

TCP™200-18-06A can be used in applications such as Heat Sinking Housing at LED-lit BLU in LCD/LED TV and LED-lit lamps such as MR16. Also it can replace the normal Aluminum heat sink.

Features

> Good thermal conductivity: 1.8W/mK
> Excellent thermal conductivity compared to normal engineering plastics
> Lighter than normal Aluminum housing 30% in weight
> Excellent mould ability in injection moulding
> Much higher production yield than normal Aluminum Die Casting
> Excellent flexibility in designing final products such as housings.

Typical Properties of TCP^TM200-18-06A
Items	Test method	Unit	Typical data
Physical Properties
Color	Visual	*****	White
Melt index	ISO 1133	g/10min	150
Specific Gravity	ISO 1183	g/cm3	1.45
Shrinkage	ISO 294	%	0.3~0.5
Mechanical Properties
Tensile Strength	ISO 527	MPa	55
Flexural Strength	ISO 178	MPa	70
Flexural Modulus	ISO 178	MPa	9000
Impact Strength, notched	ISO 180	kJ/m²	4.5
Electrical Properties
Dielectric Breakdown Voltage	ASTM D149	KV/mm	>5.5
Dielectric Constant, 1MHz	ASTM D150	*****	4.5
Volume Resistivity	ASTM D257	Ohm-meter	8.0 X 10¹²
Thermal Properties
Heat Deflection Temperature	ASTM D648	℃	180
Thermal Conductivity In Plane	ASTM D648	℃	170
Thermal Conductivity Throngh Plane	ASTM E5470	W/m-K	1.8
Flame retardancy	Min. thick. 1.0mm	Class	V-0
