Name: High Temperature Insulation Materials Silicone Thermal Insulation Pad For Heat Sink
Brand: Dongguan Ziitek Electronical Material and Technology Ltd.
SKU: TIS100-10 series
Price: 4.10 USD
Availability: InStock

Home Products Thermally Conductive Electrical Insulator

High Temperature Insulation Materials Silicone Thermal Insulation Pad For Heat Sink

Product Details:

Place of Origin:	China
Brand Name:	Ziitek
Certification:	UL & RoHS
Model Number:	TIS100-10 series

Payment & Shipping Terms:

Minimum Order Quantity:	1000pcs
Price:	0.1-10 USD/pcs
Packaging Details:	241312cm cartons
Delivery Time:	3-6 work days

Contact Now

Detailed Product Description

Product Name:	High Temperature Insulation Materials Silicone Thermal Insulation Pad For Heat Sink	Keyword:	Insulation Materials
Application:	Heat Sink	Continous Use Temp:	-45 To 200℃
Compliance:	UL & RoHS	Materials:	Ceramic Filled Silicone Elastomer
Feature:	High Thermal Conductive And Dielectric Strength	Thermal Conductive:	1.0W/mK
Highlight:	Heat Sink Silicone Thermal Insulation Pad , High Temperature Insulation Silicone Thermal Pad , High Temperature Insulation Materials Thermal Pad

High Temperature Insulation Materials Silicone Thermal Insulation Pad For Heat Sink

Ziitek Electronic Material and Technology Ltd. is dedicated to developing composite thermal solution and manufacturing superior thermal interface materials for competitive market. Our vast experience allows us to assist our customers best in thermal engineering field.We serve customers with customized products, full product lines and flexible production, which makes us be the best and reliable partner of you. Let's make your design more perfect!

The TIS™100-10 Series products are the high-efficiency insulation ones with thermal conduction properties.The supplement of the insulation base film made by silica gel into the heat-conduction material creates a great effect on both the insulation and heat conduction.

Features
> High thermal conductive and dielectric strength
> Low thermal resistance with high voltage isolation

> Easy release construction
> Electrically isolating
> High durability

Applications
> Telecommunication hardware
> Handheld portable electronics
> Semiconductor automated test equipment (ATE)
> CPU
> Display card
> Mainboard/mother board
> Notebook
> Power supply
> Heat pipe thermal solutions
> Memory Modules
> Mass storage devices
> Automotive electronics

Typical Properties of TIS100-10 series
Product Name	TIS110-10	TIS180-10	TIS1160-10	Test Method
Color	Gray			Visual
Construction &Compostion	Ceramic filled silicone elastomer / Fiberglass			*******
Composite Thickness	0.25mm	2.0mm	4.0mm	ASTM D374

Specific Gravity	1.85g/cc			ASTM D297
Tensile Strength	20kg/cm²			ASTM D412
Continuous Use Temp	-45 to 200℃			*******
Dielectric Breakdown Voltage	>10000 Vac			ASTM D149
Dielectric Constant	5.5 MHz			ASTM D150
Volume Resistivity	4.0X10¹³ Ohm-meter			ASTM D257
Flame Rating	94 V0			E331100
Thermal conductivity	1.0 W/mK			ASTM D5470

Standard Thicknesses:
(0.25mm),(2.0mm),(4.0mm)
Consult the factory alternate thickness.

Peressure Sensitive Adhesive:
Request adhesive on one side with "A1" suffix.

Request adhesive on doule side with "A2" suffix.

Standard Sizes:
12"x 160"(304mm x 48.76M)
lndividual die cut shapes can be supplied.

High Temperature Insulation Materials Silicone Thermal Insulation Pad For Heat Sink 0

Packaging Details & Lead time

1.with PET film or foam-for protection

2. use Paper Card To Separate Each Layer

3. export carton inside and outside

4. meet with customers' requirement-customized

Lead Time :Quantity(Pieces):5000

Est. Time(days): To be negotiated

Our services

Online-service : 12 hours , Inquiry reply within fastest.

Working time: 8:00am - 5:30pm, Monday to Saturday (UTC+8).

Well-trained & experienced staff are to answer all your inquiries in English of course.

Standard Export Carton Or Marked With Customer's Information Or Customized.

Provide free samples

After-service: Even our products have passed strict inspection, if you find the parts can not work well, please show us the proof.

we will help you to deal with it and give you satisfactory solution.
