2W Customized Thermal Pad Thermal Gap Filler Insulation Sheet Silicone Pad For LED CPU GPU MOS Thickness 0.5mmT

2W Customized Thermal Pad Thermal Gap Filler Insulation Sheet Silicone Pad For LED CPU GPU MOS Thickness 0.5mmT

2W Customized Thermal Pad Thermal Gap Filler Insulation Sheet Silicone Pad For LED CPU GPU MOS Thickness 0.5mmT
video
2W Customized Thermal Pad Thermal Gap Filler Insulation Sheet Silicone Pad For LED CPU GPU MOS Thickness 0.5mmT
Product Details:
Place of Origin: China
Brand Name: Ziitek
Certification: UL & RoHS
Model Number: TIF520-20-11US
Payment & Shipping Terms:
Minimum Order Quantity: 1000pcs
Price: 0.1-10 USD/PCS
Packaging Details: 24*13*12cm cartons
Delivery Time: 3-5 work days
Payment Terms: T/T
Supply Ability: 1000000 pcs/month
Contact Now
Detailed Product Description
Products Name: 2W High Quality Factory Customized Thermal Pad Thermal Gap Filler Insulation Sheet Silicone Pad For LED CPU GPU MOS Keywords: Thermal Gap Filler
Thickness: 0.5mmT Specific Gravity: 2.7g/cc
Dielectric Breakdown Voltage: >5500 VAC Thermal Conductivity: 2.0W/m-K
Color: Gray Operating Temp: -40~200℃
Application: LED CPU GPU MOS
Highlight:

0.5mmT Customized Thermal Pad

,

LED Silicone Pad Customized Thermal Pad

,

Silicone Pad Customized Thermal Pad

2W High Quality Factory Customized Thermal Pad Thermal Gap Filler Insulation Sheet Silicone Pad For LED CPU GPU MOS



Company Profile



With professional R&D capabilities and many year experiences in thermal interface material industry, Ziitek company own many unique formulations which are our core technologies and advantages. Our goal is to provide quality & competitive products to our customers worldwide aiming for long-term business cooperation.



Certifications:

ISO9001:2015

ISO14001: 2004 IATF16949:2016

IECQ QC 080000:2017

UL



Product introduction


TIF520-20-11US is a silicone based, thermally conductive gap pad. Its unreinforced construction allows additional compliancy. This product has low hardness is conformable and is electrically isolating. The low modulus characteristic of the product offers optimal thermal performance with the ease of handling.



Features
> Good thermal conductive: 2.0W/mK
> Moldability for complex parts
> Soft and compressible for low stress applications
> Broad range of hardnesses available
> Moldability for complex parts
> Outstanding thermal performance



Applications
> Cooling components to the chassis of frame
> CD-Rom, DVD-Rom cooling
> SAD-DC Power Adapters
> CPU
> Memory Modules
> Mass storage devices
> Mass storage devices
> Automotive electronics
> Set top boxes
> LED Ceilinglamp
> Monitoring the Power Box
> AD-DC Power Adapters

Typical Properties of TIF520-20-11US Series
Property Value Test method
Color Gray Visual
Construction &Compostion Ceramic filled silicone elastomer ***
Thickness range 0.5 mmT ASTM D374
Hardness 20±5 Shore 00 ASTM 2240
Specific Gravity 2.7 g/cc ASTM D792
Continuos Use Temp -40 to 200℃ ***
Dielectric Breakdown Voltage >5500 VAC ASTM D149
Dielectric Constant 4.5 MHz ASTM D150
Volume Resistivity 1.0X10¹²Ohm-meter ASTM D257
Fire rating 94 V0 UL E331100
Thermal conductivity 2.0W/m-K ASTM D5470



Packaging Details & Lead time



The packaging of thermal pad

1.with PET film or foam-for protection

2. use Paper Card To Separate Each Layer

3. export carton inside and outside

4. meet with customers' requirement-customized



Lead Time :Quantity(Pieces):5000

Est. Time(days): To be negotiated

2W Customized Thermal Pad Thermal Gap Filler Insulation Sheet Silicone Pad For LED CPU GPU MOS Thickness 0.5mmT 0
