Name: Specific Gravity 3.0 G/Cc Silicone Cpu Pad High Effective For Routers
Brand: Dongguan Ziitek Electronical Material and Technology Ltd.
SKU: TIF1180-32-05US thermal pad
Price: 4.10 USD
Availability: InStock

Home Products CPU Thermal Pad

Specific Gravity 3.0 G/Cc Silicone Cpu Pad High Effective For Routers

Product Details:

Place of Origin:	China
Brand Name:	Ziitek
Certification:	UL
Model Number:	TIF1180-32-05US thermal pad

Payment & Shipping Terms:

Minimum Order Quantity:	1000 pcs
Price:	0.1-10 USD/PCS
Packaging Details:	252413cm canton
Delivery Time:	3-8 work days
Payment Terms:	T/T
Supply Ability:	100000pcs/month

Contact Now

Detailed Product Description

Specific Gravity:	3.0 G/cc	Name:	Specific Gravity 3.0 G/cc High Cost-effective CPU Thermal Pad For Routers
Keyword:	Thermal Gap Pad	Dielectric Constant@1MHz:	4.0 MHz
Thermal Conductivity:	3.2 W/m-K	Hardness:	20 Shore 00
Highlight:	3.2 w mk silicone cpu pad , silicone cpu pad for routers , pad cpu for routers

Specific Gravity 3.0 g/cc High Cost-effective CPU Thermal Pad for Routers

Company Profile

With professional R&D capabilities and over 13 year experiences in thermal interface material industry, Ziitek company own many unique formulations which are our core technologies and advantages. Our goal is to provide quality & competitive products to our customers worldwide aiming for long-term business cooperation.

TIF100-32-05US-Series-Datasheet-REV02.pdf

Ziitek TIF1180-32-05US thermal silicone pad is a product with both performance and economy. It is a unique thermal pad with low oil permeability, low thermal resistance, high softness and high compliance.It can work stably at -40℃~160℃ and meet the requirement of UL94V0.

<Good thermal conductive:3.2W/mK

<Thickness:4.5mmT

<Hardness:20 Shore 00

<Colour: blue

<Moldability for complex parts

<Soft and compressible for low stress applications

<Naturally tacky needing no further adhesive coating

Applications

<Waterproof LED Power

<SMD LED module

<LED Flesible strip, LED bar

<LED PanelLight

<LED floor light

<Routers

Typical Properties of TIF1180-32-05US
Product Name	TIF1180-32-05US Series
Colour	blue
Construction & Compostion	Ceramic filled silicone elastomer
Specific gravity	3.0 g/cc
Thickness	4.5mmT
Hardness	20 Shore 00
Dielectric constant@1MHz	4.0 MHz
Continuos Use Temp	-40 to 160℃
Dielectric Breakdown Voltage	>5500 VAC
Thermal conductivity	3.2 W/mK
Volume Resistivity	1.0*10^12 _Ohm-cm

Standard Sheets Sizes:

8" x 16"(203mm x 406mm)

TIF™ series Individual die cut shapes can be supplied

Ziitek Culture

Quality :

Do it right the first time, total quality control

Effectiveness:

Work precisely and thoroughly for effectiveness

Service:

Quick response, On time delivery and Excellent service

Team work:

Complete teamwork, including sales team, Marketing team, engineering team, R&D team, Manufacturing team, logistics team. All is for supporting and servicing a satisfy service for customers.

Specific Gravity 3.0 G/Cc Silicone Cpu Pad High Effective For Routers 1

FAQ

Q: How long is your delivery time?

A: Generally it is 3-7 work days if the goods are in stock. or it is 7-10 work days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra cost?

A: Yes, we could offer samples free of charge

Tag:

laptop gpu thermal pad,

cpu cooling pad,

notebook thermal pad

Contact Details

Dongguan Ziitek Electronical Material and Technology Ltd.

Contact Person: Dana Dai

Tel: +86 18153789196
