4.7 MHz Heat Sink Thermal Pad Malleability For Complex Parts For LED Flexible Strip

4.7 MHz Heat Sink Thermal Pad Malleability For Complex Parts For LED Flexible Strip

4.7 MHz Heat Sink Thermal Pad Malleability For Complex Parts For LED Flexible Strip
video
4.7 MHz Heat Sink Thermal Pad Malleability For Complex Parts For LED Flexible Strip
Product Details:
Place of Origin: China
Brand Name: Ziitek
Certification: UL
Model Number: TIF160N-50-10F thermal pad
Payment & Shipping Terms:
Minimum Order Quantity: 1000 pcs
Price: 0.1-10 USD/PCS
Packaging Details: 25*24*13cm canton
Delivery Time: 3-8 work days
Payment Terms: T/T
Supply Ability: 100000pcs/month
Contact Now
Detailed Product Description
Application: Waterproof LED Power Thickness: 1.5mmT
Keyword: Thermal Gap Pad Name: 4.7 MHz Moldability For Complex Parts Heat Sink Pad For LED Flesible Strip
Flame Rating: 94-V0 Construction & Compostion: Ceramic Filled Silicone Elastomer
High Light:

4.7 MHz heat sink thermal pad

,

1.5mm heat sink thermal pad

,

LED Flexible Strip heat sink pad

4.7 MHz Moldability for Complex Parts Heat Sink Pad for LED Flesible Strip



Company Profile

With a wide range, good quality, reasonable prices and stylish designs, Ziitek thermal conductive interface materials are extensively used in Mainboards, VGA cards, Notebooks, DDR&DDR2 products, CD-ROM ,LCD TV, PDP products, Server Power products, Down lamps, Spotlights, Street lamps, Daylight lamps, LED Server Power products and others.


TIF100N-50-10F-Specification-sheet.pdf



Ziitek TIF160N-50-10F thermal silicone pad is a product with both performance and economy. It is a unique thermal pad with low oil permeability, low thermal resistance, high softness and high compliance.It can work stably at -40℃~160℃ and meet the requirement of UL94V0.




<Good thermal conductive: 5.0 W/mK
<Thickness: 1.5mmT
<Hardness:55±5 Shore 00
<Colour: gray

<Good thermal conductive
<Moldability for complex parts
<Soft and compressible for low stress applications







Applications

<Waterproof LED Power
<SMD LED module
<LED Flesible strip, LED bar
<LED PanelLight
<LED floor light
<Routers



Typical Properties of TIF160N-50-10F

Product Name TIF160N-50-10F Series
Colour Gray
Construction & Compostion Ceramic filled silicone elastomer
Specific gravity

2.1 g/cm^3

Thickness 1.5mmT
Hardness 55±5 Shore 00
Dielectric constant@1MHz 4.7 MHz
Continuos Use Temp -40 to 160℃
Dielectric Breakdown Voltage >5500 VAC
Thermal conductivity 5.0W/mK
Flame Rating 94-V0



Standard Thicknesses:

0.020" (0.51mm) 0.030" (0.76mm)
0.040" (1.02mm) 0.050" (1.27mm) 0.060" (1.52mm)
0.070" (1.78mm) 0.080" (2.03mm) 0.090" (2.29mm)
0.100" (2.54mm) 0.110" (2.79mm) 0.120" (3.05mm)
0.130" (3.30mm) 0.140" (3.56mm) 0.150" (3.81mm)
0.160" (4.06mm) 0.170" (4.32mm) 0.180" (4.57mm)
0.190" (4.83mm) 0.200" (5.08mm)

Consult the factory to alternate thickness.





4.7 MHz Heat Sink Thermal Pad Malleability For Complex Parts For LED Flexible Strip 0




Ziitek Culture

Quality :
Do it right the first time, total quality control
Effectiveness:
Work precisely and thoroughly for effectiveness
Service:
Quick response, On time delivery and Excellent service
Team work:
Complete teamwork, including sales team, Marketing team, engineering team, R&D team, Manufacturing team, logistics team. All is for supporting and servicing a satisfy service for customers.



4.7 MHz Heat Sink Thermal Pad Malleability For Complex Parts For LED Flexible Strip 1

FAQ

Q:Do big buyers have promotional prices?
A: Yes, if you are a big buyer in a certain area, Ziitek will provide you with promotional prices, which will help you start your business here. Buyers with long-term cooperation will have better prices.
Q: Are you trading company or manufacturer ?
A: We are manufacturer in China.
