2.5mmT Easy Release Construction Conductive Pads for LED Power Supply

2.5mmT Easy Release Construction Conductive Pads for LED Power Supply

2.5mmT Easy Release Construction Conductive Pads for LED Power Supply
video
2.5mmT Easy Release Construction Conductive Pads for LED Power Supply
Product Details:
Place of Origin: China
Brand Name: Ziitek
Certification: UL
Model Number: TIF2100-20-02ES thermal pad
Payment & Shipping Terms:
Minimum Order Quantity: 1000 pcs
Price: 0.1-10 USD/PCS
Packaging Details: 25*24*13cm canton
Delivery Time: 3-8 work days
Payment Terms: T/T
Supply Ability: 100000pcs/month
Contact Now
Detailed Product Description
Name: 2.5mmT Easy Release Construction Conductive Pads For LED Power Supply Thermal Conductive: 2.0 W/mK
Keyword: Thermal Gap Pad Colour: Pink/White
Hardness: 10 Shore 00 Dielectric Constant@1MHz: 5.0 MHz
High Light:

Construction Conductive Pads

,

2.5mmT Conductive Pads

,

LED Power Supply Thermal Pad

2.5mmT Easy Release Construction Conductive Pads for LED Power Supply



Company Profile

Ziitek Electronic Material and Technology Ltd. is a R&D and production company, we have many production lines and processing technology of thermal conductive materials, owns advanced production equipment and optimized process, can provide various thermal solutions for different applications.



TIF200-20-02ES-Series-Datasheet.pdf



Ziitek TIF2100-20-02ES use a special process, with silicone as the base material, adding thermal conductive powder and flame retardant together to make the mixture to become thermal interface material. This is effective in lower the thermal resistance between the heat source and the heat sink.




<Good thermal conductive: 2.0 W/mK
<Thickness: 2.5mmT
<Hardness:10 Shore 00
<Colour: Pink/White

<Easy release construction
<Electrically isolating
<High durability













Applications

<LED Power Supply

<LED Controller

<LED Ceilinglamp

<Monitoring the Power Box

<AD-DC Power Adapters

<Rainproof LED Power






Typical Properties of TIF2100-20-02ES

Product Name TIF2100-20-02ES Series
Colour Pink/White
Construction & Compostion Ceramic filled silicone elastomer
Specific gravity

2.8 g/cm^3

Thickness 2.5mmT
Hardness 10 Shore 00
Dielectric constant@1MHz 5.0 MHz
Continuos Use Temp -40 to 160℃
Dielectric Breakdown Voltage >5000 VAC
Thermal conductivity 2.0W/mK
Flame Rating 94-V0




Standard Thicknesses:



0.020" (0.51mm) 0.030" (0.76mm)

0.040" (1.02mm) 0.050" (1.27mm) 0.060" (1.52mm)

0.070" (1.78mm) 0.080" (2.03mm) 0.090" (2.29mm)

0.100" (2.54mm) 0.110" (2.79mm) 0.120" (3.05mm)

0.130" (3.30mm) 0.140" (3.56mm) 0.150" (3.81mm)

0.160" (4.06mm) 0.170" (4.32mm) 0.180" (4.57mm)

0.190" (4.83mm) 0.200" (5.08mm)



Consult the factory to alternate thickness.
