Name: 4.5 MHz Good Thermal Conductive Thermal Pad for Automotive Electronics
Brand: Dongguan Ziitek Electronical Material and Technology Ltd.
SKU: TIF740HM thermal pad
Price: 4.10 USD
Availability: InStock

Home Products Heat Sink Thermal Pad

4.5 MHz Good Thermal Conductive Thermal Pad for Automotive Electronics

Product Details:

Place of Origin:	China
Brand Name:	Ziitek
Certification:	UL
Model Number:	TIF740HM thermal pad

Payment & Shipping Terms:

Minimum Order Quantity:	1000 pcs
Price:	0.1-10 USD/PCS
Packaging Details:	252413cm canton
Delivery Time:	3-8 work days
Payment Terms:	T/T
Supply Ability:	100000pcs/month

Contact Now

Detailed Product Description

Part Number:	TIF740HM	Material:	Silicone
Specific Gravity:	3.3 G/cm^3	Name:	4.5 MHz Good Thermal Conductive Thermal Pad For Automotive Electronics
Keyword:	Thermal Gap Pad	Application:	Heat Pipe Thermal Solutions
Highlight:	4.5 MHz Conductive Thermal Pad , 3.3g/cm3 Conductive Thermal Pad , Automotive Heat Sink Thermal Pad

4.5 MHz Good Thermal Conductive Thermal Pad for Automotive Electronics

Company Profile

With a wide range, good quality, reasonable prices and stylish designs, Ziitek thermal conductive interface materials are extensively used in Mainboards, VGA cards, Notebooks, DDR&DDR2 products, CD-ROM ,LCD TV, PDP products, Server Power products, Down lamps, Spotlights, Street lamps, Daylight lamps, LED Server Power products and others.

TIF700HM-Series-Datasheet.pdf

Ziitek TIF740HM use a special process, with silicone as the base material, adding thermal conductive powder and flame retardant together to make the mixture to become thermal interface material. This is effective in lower the thermal resistance between the heat source and the heat sink.

< Good thermal conductive: 6.0 W/mK

< Thickness: 1.0mmT

< Hardness: 45±5 Shore 00

< Colour: Grey

< Electrically isolating
< High durability
< Good thermal conductive

Applications

<Automotive electronics

<Set top boxes

<Audio and video components

<IT infrastructure

<GPS navigation and other portable devices

<CD-Rom, DVD-Rom cooling

Typical Properties of TIF740HM
Product Name	TIF740HMSeries
Colour	Grey
Construction & Compostion	Ceramic filled silicone elastomer
Specific gravity	3.3 g/cm³
Thickness	1.0mmT
Hardness	45±5 Shore 00
Dielectric constant@1MHz	4.5 MHz
Continuos Use Temp	-40 to 160℃
Dielectric Breakdown Voltage	>5500 VAC
Thermal conductivity	6.0W/mK
Flame Rating	94-V0

Packaging Details & Lead time

The packaging of thermal pad

1.with PET film or foam-for protection

2. use Paper Card To Separate Each Layer

3. export carton inside and outside

4. meet with customers' requirement-customized

Lead Time :Quantity(Pieces):5000

Est. Time(days): To be negotiated

Independent R&D team

Q: How do I place an order?

A:1. Click the "Sent messages" button to continue with the process.

2. Fill out the message form by entering a subject line, and message to us.

This message should include any questions you might have about the products as well as your purchase requests.

3. Click the "Send" button when you are finished to complete the process and send your message to us

4. We will reply you as soon as possible with Email or online

4.5 MHz Good Thermal Conductive Thermal Pad for Automotive Electronics 1

FAQ

Q: What kind of packaging you offer?

A: During the packaging process, preventive measures will be taken by us to assure that the goods are in a good condition during storage and delivery.

Q:Do big buyers have promotional prices?

A: Yes, if you are a big buyer in a certain area, Ziitek will provide you with promotional prices, which will help you start your business here. Buyers with long-term cooperation will have better prices.

Tag:
