1.5MM Silicone Conductive Cooling Interface Material Soft Gpu Cpu Led Thermal Pad

1.5MM Silicone Conductive Cooling Interface Material Soft Gpu Cpu Led Thermal Pad

Product Details:
Place of Origin: China
Brand Name: Ziitek
Certification: UL
Model Number: TIF760PES thermal pad
Payment & Shipping Terms:
Minimum Order Quantity: 1000 pcs
Price: 0.1-10 USD/PCS
Packaging Details: 24*13*12cm cartons
Delivery Time: 3-8 work days
Payment Terms: T/T
Supply Ability: 100000pcs/month
Contact Now
Detailed Product Description
Products Name: 1.5MM Silicone Conductive Cooling Interface Material Soft Gpu Cpu Led Thermal Pad Density: 3.4g/cm³
Hardness: 55/10 Keyword: Led Thermal Pad
Thickness: 1.5mmT Thermal Conductivity: 7.5W/mK
Application: Gpu Cpu Led Heat Dissipation Construction: Ceramic Filled Silicone Elastomer
Highlight:

1.5MM Silicone Conductive Cooling Interface Material

,

Soft Gpu Cpu Led Thermal Pad

1.5MM Silicone Conductive Cooling Interface Material Soft Gpu Cpu Led Thermal Pad



Company Profile



Dongguan Ziitek Electronic Material Technology Co., Ltd. was established in 2006. Is a high-tech enterprise specializing in the research, development, production and sales of thermal interface materials. We mainly produce: heat-conducting joint filler, low melting point thermal interface materials, heat-conducting insulator, heat-conducting adhesive tape, heat-conducting interface pad and heat-conducting grease, heat-conducting plastic, silicone rubber, silicone rubber foam, etc. We adhere to the business philosophy of "survival by quality, development by quality", and continue to provide the most efficient and best service for new and old customers with excellent quality in the spirit of rigor, pragmatism and innovation.

1.5MM Silicone Conductive Cooling Interface Material Soft Gpu Cpu Led Thermal Pad 0

Products description



The TIF®700PES Series is a thermal pad specifically designed to tackle the high level cooling challenges and environments sensitive to extreme mechanical stress. It combines excellent thermal conductivity with a near-fluid ultimate softness, ensuring perfect filling of the contact interface even under ultra-low mounting pressure,completely eliminating air thermal resistance,and providing superior thermal solutions and physical protection for the most precise and highest heat flux electronic components.

Features:

> High thermal conductivity: 7.5W/mK

> Extremely soft,low compression stress effectively protects sensitive components
> Self-adhesive without the need for additional surface adhesives
> High insulation performance

> Available in varies thicknesses
> Broad range of hardnesses available


Applications



> AI Servers

> Semiconductor Packaging
> Low-Altitude Aircraft
> Optical Communication Products
> 5G Base Stations

> Routers
> Medical Devices
> Auditioning electronic products
> unmanned aerial vehicle(UAV)
> Photovoltaic



Typical Properties of TIF®700PES Series
Property Value Test method
Color Gray Visual
Construction & Compostion Ceramic filled silicone elastomer ******
Density(g/cm³) 3.4 ASTM D792
Thickness Range(inch/mm)

0.020~0.030

(0.50~0.75)

0.040~0.200 (1.0~5.00) ASTM D374
Hardness 55 Shore 00 10 Shore 00 ASTM 2240
Recommended Operating Temperature -40 to 200℃ ******
Breakdown Voltage(V/mm) ≥5500 ASTM D149
Dielectric Constant 7.6 MHz ASTM D150
Volume Resistivity >1.0X1012 Ohm-meter ASTM D257
Flame rating V-0 UL 94 (E331100)
Thermal conductivity 7.5 W/m-K ASTM D5470
7.5 W/m-K ISO22007



Product Specifications


Standard Thickness: 0.020"(0.50 mm)~ 0.20" (5.00 mm) with increments of 0.010 inch (0.25 mm).
Standard Size: 16"×16" (406 mm ×406 mm)



The TIF® series is available in custom shapes and various forms.

For other thicknesses or more information, please contact us.

1.5MM Silicone Conductive Cooling Interface Material Soft Gpu Cpu Led Thermal Pad 1

Our services



Online-service : 12 hours , Inquiry reply within fastest.


Working time: 8:00am - 5:30pm, Monday to Saturday (UTC+8).

Well-trained & experienced staff are to answer all your inquiries in English of course.

Standard Export Carton Or Marked With Customer's Information Or Customized.

Provide free samples



After-service: Even our products have passed strict inspection, if you find the parts can not work well, please show us the proof.

we will help you to deal with it and give you satisfactory solution.



FAQ



Q: Do you accept custom orders ?

A:Yes , welcome to custom orders. Our custom elements including dimension , shape , color and coated on side or two sides adhesive or coated fiberglass. If you want to place a custom order , pls kindly offer a drawing or leave your custom order information .



Q: How much are the pads?

A: Price is depended on your size, thickness, quantity, and other requirements, such as adhesive and others. Please let us know these factors first so that we could give you an exact price.



Q: What thermal conductivity test method was used to achieve the values given on the data sheets?

A: A test fixture is utilized that meets the specifications outlined in ASTM D5470.



Q: Is GAP PAD offered with an adhesive?

A: Currently, Most of thermal gap pad surface has double side natural inherent tack,Non-stick surface can also be treated according to customer's requirements.
