| Place of Origin: | China |
| Brand Name: | Ziitek |
| Certification: | RoHS |
| Model Number: | TIG780-52 |
| Minimum Order Quantity: | 5kg |
|---|---|
| Price: | USD 1-100/KG |
| Packaging Details: | 1kg/can |
| Delivery Time: | 3-5 work days |
| Payment Terms: | TT |
| Supply Ability: | 10000KG/month |
| Name: | White Thermal Grease With High Performance Widely Used For Computer CPU | Keywords: | Thermal Conductive Grease |
|---|---|---|---|
| Application: | CPU,Display Card,Mainboard/mother Board | Thermal Conductivity: | 5.2 W/mK |
| Material: | Metal Oxide Filled Silicone Oil | Color: | Gray |
| Highlight: | Computer CPU Thermal Grease,Gray Thermal Grease,Metal Oxide Filled Thermal Grease |
||
Gray thermal grease with high performance widely used for computer CPU
TIG™780-52 is environmentally safe silicone-based thermal grease designed to solve overheating and reliability issues.
TIG™780-52 is a heat conducting product in the shape of paste.They serve to moisten the contact surface sufficiently so as to form an interface of extremely low thermal impedance .Consequently, the heat dissipation efficiency is far superior to that offered by others.
Features
> Low thermal impedance.
> Good thermal conductivity.
> Non-toxic and environmentally safe.
> Excellent long term stability.
> Thoroughly wets out contact surfaces to create low thermal resistance.
Applications
> Semiconductor cases and heat sinks
> Chipsets and Graphic processing
> CPU's and GPU's
> Automatic dispensing and screen-printing
> LED, set top box.
| Typical Properties of TIG™780-52 Series | ||
| Product Name | TIG™780-52 | Test Method |
| Color | Gray | Visual |
| Construction | Metal oxide filled silicone oil | Ziitek Test Method |
| Specific Gravity | 2.3 g/cm3 | ASTM 297 |
| Thermal Conductivity | 5.2W/mK | ASTM D5470 |
| Bond line Thickness(mm) | 0.008 | ASTM D374 |
| Themal Impedance(℃-in²/W )@ 30 psi | 0.015 | ASTM D5470 |
| Themal Impedance(℃-in²/W )@ 50 psi | 0.012 | ASTM D5470 |
| Recommended operating Temp(℃) | -45℃ to 200℃ | Ziitek Test Method |
| Fire rating | V-0 | UL 94 |
| Viscosity (mPa.s) | 200000 | GB/T 10247 |
Package
5g ~ 50g for the needle cylinder; Cans of 300ml,; 600ml ; 1200ml
Storage:
Store from 5°C to 25°C with a maximum humidity of 70%.Do not store in freezer or refrigerator below 0° C.Safe disposal method does not require special protection. The storage condition is low temperature and dry, away from open fire and away from direct sunlight. For detailed method, please refer to the product material safety data sheet.
