Name: Electrical Insulating Thermal Grease Heat Transfer Silicone Paste For LED GPU PC laptop
Brand: Dongguan Ziitek Electronical Material and Technology Ltd.
SKU: TIG780-12 Series
Price: 50.00 USD
Availability: InStock

Home Products High Temperature Thermal Grease

Electrical Insulating Thermal Grease Heat Transfer Silicone Paste For LED GPU PC laptop

Product Details:

Place of Origin:	China
Brand Name:	Ziitek
Certification:	RoHS
Model Number:	TIG780-12 Series

Payment & Shipping Terms:

Minimum Order Quantity:	5kg
Price:	USD 1-100/KG
Packaging Details:	1kg/can
Delivery Time:	3-5 work days
Payment Terms:	TT
Supply Ability:	10000KG/month

Contact Now

Detailed Product Description

Name:	Premium Performance Electrical Insulating Thermal Grease Silicone Heat Transfer Silicone Paste For LED GPU PC Laptop	Keywords:	Thermal Grease
Application:	LED GPU PC Laptop	Thermal Conductivity:	1.2 W/mK
Material:	Metal Oxide Filled Silicone Oil	Color:	White
Highlight:	LED GPU Thermal Grease , Heat Transfer Silicone Paste , PC laptop Thermal Grease

Premium Performance Electrical Insulating Thermal Grease Silicone Heat Transfer Silicone Paste For LED GPU PC laptop

TIG™780-12 is environmentally safe silicone-based thermal grease designed to solve overheating and reliability issues.

TIG™780-12 is a heat conducting product in the shape of paste.They serve to moisten the contact surface sufficiently so as to form an interface of extremely low thermal impedance .Consequently, the heat dissipation efficiency is far superior to that offered by others.

TIG780-12-TDS_EN_REV01.pdf

Features

> Low thermal impedance.

> Good thermal conductivity.
> Non-toxic and environmentally safe.

> Excellent long term stability.
> Thoroughly wets out contact surfaces to create low thermal resistance.

Applications

> CPUs and GPUs
> Automatic dispensing and screen-printing
> Mobile, desktop
> Engine and transmission control modules
> Memory modules
> Power conversion equipment
> Power supplies and UPS

Typical Properties of TIG™780-12
ProductName	TIG™780-12	Test Method
Color	White	Visual
Construction & Compostion	Metal oxide filled	*******
Density(g/cm³)	2.5	ASTM D297
Thermal Conductivity	1.2 W/mK	ASTM D5470
Thermal lmpedance@10psi	≤0.085 ℃*in²/w	ASTM D5470
Thermal lmpedance@50psi	≤0.085 ℃*in²/w	ASTM D5470
Viscosity(mPa.s)	130000	GB/T 10247

Package:

Cans of 300ml ~ 1000ml, 500g ~2kg

Storage:

Store from 5°C to 25°C with a maximum humidity of 70%.Do not store in freezer or refrigerator below 0° C.Safe disposal method does not require special protection. The storage condition is low temperature and dry, away from open fire and away from direct sunlight. For detailed method, please refer to the product material safety data sheet.

Company profile

Ziitek company is a high-tech enterprise which dedicated to the R&D, manufacture and sales of the thermal interface materials (TIMs). We have rich experiences in this field which can support you the latest, most effective and one -step thermal management solutions. We have many advanced production equipments,full test equipments and fully automatic coating production lines which can support the production for high performance thermal silicone pad, thermal graphite sheet/ film, thermal double-sided tape, thermal insulation pad, thermal ceramic pad, phase change material, thermal grease etc. UL94 V-0, SGS and ROHS are compliant.

Ziitek Culture

Quality :

Do it right the first time, total quality control

Effectiveness:

Work precisely and thoroughly for effectiveness

Service:

Quick response, On time delivery and Excellent service

Team work:

Complete teamwork, including sales team, Marketing team, engineering team, R&D team, Manufacturing team, logistics team. All is for supporting and servicing a satisfy service for customers.

Electrical Insulating Thermal Grease Heat Transfer Silicone Paste For LED GPU PC laptop 1
