Name: High Thermal Conductivity Paste 2.5W/MK CPU GPU Display Card High Voltage Thermal Grease
Brand: Dongguan Ziitek Electronical Material and Technology Ltd.
SKU: TIG780-25
Price: 50.00 USD
Availability: InStock

Home Products High Temperature Thermal Grease

High Thermal Conductivity Paste 2.5W/MK CPU GPU Display Card High Voltage Thermal Grease

Product Details:

Place of Origin:	China
Brand Name:	Ziitek
Certification:	RoHS
Model Number:	TIG780-25

Payment & Shipping Terms:

Minimum Order Quantity:	5kg
Price:	USD 1-100/KG
Packaging Details:	1kg/can
Delivery Time:	3-5 work days
Payment Terms:	TT
Supply Ability:	10000KG/month

Contact Now

Detailed Product Description

Products Name:	High Thermal Conductivity Paste 2.5W/MK CPU GPU Display Card Minier Machine High Voltage Thermal Grease	Keywords:	Thermal Grease
Application:	Electronic Component Gap Filling	Material:	Heat Conduction Filler / Silicone Oil
Continuous Use Temp:	-45~200℃	Color:	Gray
Thermal Conductivity:	2.5W/mK
Highlight:	High Voltage High Thermal Conductivity Paste , 3.0W/MK High Thermal Conductivity Paste , Miner Machine High Voltage Thermal Grease

High Thermal Conductivity Paste 2.5W/MK CPU GPU Display Card Minier Machine High Voltage Thermal Grease

TIG™780-25 is environmentally safe silicone-based thermal grease designed to solve overheating and reliability issues.

TIG™780-25 is a heat conducting product in the shape of paste. They serve to moisten the contact surface sufficiently so as to form an interface of extremely low thermal impedance.Consequently, the heat dissipation efficiency is far superior to that offered by others.

High Thermal Conductivity Paste 2.5W/MK CPU GPU Display Card High Voltage Thermal Grease 0

Features

> Good thermal conductivity 2.5W/mK

> Low thermal impedance

> Non-toxic and environmentally safe

> Excellent long term stability

> Thoroughly wets out contact surfaces to create. low thermal impedance.

Applications

> Cooling components to the chassis of frame
> High speed mass storage drives
> Heat Sinking Housing at LED-lit BLU in LCD
> LED TV and LED-lit lamps
> RDRAM memory modules
> Micro heat pipe thermal solutions
> Automotive engine control units
> CPU

Typical Properties of TIG™780-25 Series
ProductName	TIG™780-25	Test Method
Color	Gray	Visual
Construction & Compostion	Metal oxide filler	Ziitek Test Method
Specific Gravity(g/cm³)	2.5	ASTM D297
Thermal Conductivity	2.5W/mK	ASTM D5470
Bond line thickness(mm)	0.014	ASTM D5470
Thermal lmpedance(℃.in²/W) @50psi	0.02	ASTM D5470
Continuous Use Temp (℃)	-45~200℃	Ziitek Test Method
Viscosity(mPa.s)	1480K	GB/T 10247

Package:

Packing specification 0.5kg,1kg,2kg; For other specifications, please contact us.

Storage:

Store from 5° C to 25°C with a maximum humidity of 70%.Do not store in freezer or refrigerator below 0° C.Safe disposal method does not require special protection.The storage condition is low temperature and dry, away from open fire and away from direct sunlight. For detailed method, please refer to the product material safety data sheet.

Company profile

Ziitek Electronic Material and Technology Ltd. is a R&D and production company, we have many production lines and processing technology of thermal conductive materials, owns advanced production equipment and optimized process, can provide various thermal solutions for different applications.

Our services

Online-service : 12 hours , Inquiry reply within fastest.

Working time: 8:00am - 5:30pm, Monday to Saturday (UTC+8).

Well-trained & experienced staff are to answer all your inquiries in English of course.

Standard Export Carton Or Marked With Customer's Information Or Customized.

Provide free samples

After-service: Even our products have passed strict inspection, if you find the parts can not work well, please show us the proof.

we will help you to deal with it and give you satisfactory solution.
