Name: 6.5W/MK Silicone-Based Thermal Management Thermal GAP PAD Materials For Network Communication Products
Brand: Dongguan Ziitek Electronical Material and Technology Ltd.
SKU: TIF500-65-11ES
Price: 4.10 USD
Availability: InStock

Home Products Heat Sink Thermal Pad

6.5W/MK Silicone-Based Thermal Management Thermal GAP PAD Materials For Network Communication Products

Product Details:

Place of Origin:	China
Brand Name:	Ziitek
Certification:	UL & RoHS
Model Number:	TIF500-65-11ES

Payment & Shipping Terms:

Minimum Order Quantity:	1000pcs
Price:	0.1-10 USD/PCS
Packaging Details:	241312cm cartons
Delivery Time:	3-5 work days
Payment Terms:	T/T
Supply Ability:	1000000 pcs/month

Contact Now

Detailed Product Description

Products Name:	6.5W/MK Silicone-Based Thermal Management Thermal GAP PAD Materials For Network Communication Products	Sample:	Sample Free
Breakdown Voltage（V/mm）:	≥5500	Fire Rating:	94 V0
Color:	Dark Gray	Thermal Conductivity:	6.5W/m-K
Keywords:	Thermal GAP PAD Materials	Dielectric Constant @ 1MHz:	7.0MHz
Thickness Range:	0.020"~0.200"(0.50mm~5.0mm)	Application:	Network Communication Products Cooling

6.5W/MK Silicone-Based Thermal Management Thermal GAP PAD Materials For Network Communication Products

Company Profile

A silicone thermal pad is a type of thermal interface material (TIM) which is highly conductive and comprises of conformable materials which are used to provide a heat path between heat sinks and electronic devices where uneven surface topography, air gaps and texture preclude good thermal transfer. Ziitek supply a wide range of silicone thermal pads with varying properties to suit every application.

The TIF^®500-65-11ES Series is a thermal pad specifically designed to tackle the high level cooling challenges and environments sensitive to extreme mechanical stress. It combines higt thermal conductivity with a near-fluid ultimate softness, ensuring perfect filling of the contact interface even under ultra-low mounting pressure, completely eliminating air thermal resistance,and providing superior thermal solutions and physical protection for the most precise and higt heat flux electronic components.

Features

> High thermal conductivity
> Extremely soft,low compression stress effectively protects sensitive components
> Self-adhesive without the need for additional surface adhesives
> Good insulation performance

Applications

> Computer / communication equipment.
> Laptop / tablet / PC server.
> New energy power battery / vehicle equipment.
> Switching power supply / UPS.
> Video / security equipment.
> Any heating element and radiator.

> Routers
> Medical Devices
> Auditioning electronic products
> Unmanned aerial vehicle(UAV)

> Photovoltaic
> Signal communication
> New energy vehicle

Typical Properties of TIF^®500-65-11ES Series
Property	Value		Test method
Color	Dark Gray		Visual
Construction & Compostion	Ceramic filled silicone elastomer		******
Density(g/cm³)	3.4		ASTM D792
Thickness Range(inch/mm)	0.020~0.030	0.040~0.200	ASTM D374
	(0.50~0.75)	(1.00~5.00)
Hardness	20 Shore 00	10 Shore 00	ASTM 2240
Continuos Use Temp	-40 to 200℃		******
Breakdown Voltage(V/mm)	≥ 5500		ASTM D149
Dielectric Constant	7.0 MHz		ASTM D150
Volume Resistivity	＞1.0X10¹² Ohm-meter		ASTM D257
Thermal Conductivity (W/m-K)	6.5		ASTM D5470
	6.5		ISO22007
Fire rating	V-0		UL 94 (E331100)

Product Specifications
Standard Thickness: 0.020" (0.50 mm)～ 0.200" (5.00 mm) with increments of 0.010" (0.25 mm).
Standard Size: 16"×16" (406 mm ×406 mm).

Component Codes:
Reinforcement Fabric: FG (Fiberglass).
Coating Options: NS1 (Non-adhesive treatment),
DC1 (Single-sided hardening).
Adhesive Options: A1/A2 (Single-sided/Double-sided adhesive).

The TIF^® series is available in custom shapes and various forms.
For other thicknesses or more information, please contact us.

6.5W/MK Silicone-Based Thermal Management Thermal GAP PAD Materials For Network Communication Products 0

Packaging Details & Lead time

The packaging of thermal pad

1.with PET film or foam-for protection

2. use Paper Card To Separate Each Layer

3. export carton inside and outside

4. meet with customers' requirement-customized

Lead Time :Quantity(Pieces):5000

Est. Time(days): To be negotiated

Ziitek Culture

Quality :

Do it right the first time, total quality control

Effectiveness:

Work precisely and thoroughly for effectiveness

Service:

Quick response, On time delivery and Excellent service

Team work:

Complete teamwork, including sales team, Marketing team, engineering team, R&D team, Manufacturing team, logistics team. All is for supporting and servicing a satisfy service for customers.

FAQ:

Q: Are you trading company or manufacturer ?

A: We are manufacturer in China.

Q: How long is your delivery time?

A: Generally it is 3-7 work days if the goods are in stock. or it is 7-10 work days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra cost?

A: Yes, we could offer samples free of charge.
