Name: Popular UL Recognized IATF16949 Thermal Gap Filler Pad 1.5W/MK Good Thermal Conductive For Display Card
Brand: Dongguan Ziitek Electronical Material and Technology Ltd.
SKU: TIF160-01E Series
Price: 4.10 USD
Availability: InStock

Home Products Silicone Thermal Pad

Popular UL Recognized IATF16949 Thermal Gap Filler Pad 1.5W/MK Good Thermal Conductive For Display Card

Product Details:

Place of Origin:	China
Brand Name:	Ziitek
Certification:	UL & RoHS
Model Number:	TIF160-01E Series

Payment & Shipping Terms:

Minimum Order Quantity:	1000pcs
Price:	0.1-10 USD/PCS
Packaging Details:	241312cm cartons
Delivery Time:	3-5 work days
Payment Terms:	T/T
Supply Ability:	1000000 pcs/month

Contact Now

Detailed Product Description

Products Name:	Popular UL Recognized IATF16949 Thermal Gap Filler Pad 1.5W/MK Good Thermal Conductive For Display Card	Thickness:	0.5-5.0mmT
Specific Gravity:	2.3 G/cc	Dielectric Breakdown Voltage:	>5500 VAC
Thermal Conductivity:	1.5W/m-K	Keywords:	Thermal Gap Filler Pad
Application:	Display Card
Highlight:	Thermal Gap Filler Pad 1.5W/MK , Thermal Gap Filler Pad IATF16949 , Silicone Thermal Pad 35 Shore 00

Popular UL Recognized IATF16949 Thermal Gap Filler Pad 1.5W/MK Good Thermal Conductive For Display Card

Company Profile

With a wide range, good quality, reasonable prices and stylish designs, Ziitek thermal conductive interface materials are extensively used in Mainboards, VGA cards, Notebooks, DDR&DDR2 products, CD-ROM ,LCD TV, PDP

products, Server Power products, Down lamps, Spotlights, Street lamps, Daylight lamps, LED Server Power products and others.

The TIF160-01E Series thermal silicone pad is a product with both performance and economy. It is a unique thermal pad with low oil permeability, low thermal resistance, high softness and high compliance.It can work stably at -40℃~160℃ and meet the requirement of UL94V0.

TIF100-01E Datasheet-REV02.pdf

Features

> Good thermal conductive: 1.5W/mK
> Available in varies thickness
> UL recognized
> Broad range of hardnesses available
> High tack surface reduces contact resistance

Applications

> LED TV / LED Lit Lamps
> CD-Rom, DVD-Rom cooling
> SAD-DC Power Adapters
> CPU
> Memory Modules
> routers
> Telecommunication hardware

Typical Properties of TIF160-01E Series
Color	Black	Visual
Construction & Compostion	Ceramic filled silicone elastomer	******

Specific Gravity	2.3 g/cc	ASTM D297

Thickness range	0.020"-0.200"	ASTM C351

Hardness	35 Shore 00	ASTM 2240

Dielectric Breakdown Voltage	>5500 VAC	ASTM D412

Continuos Use Temp	-40 to 160℃	******

Outgassing(TML)	0.35%	ASTM E595

Dielectric Constant	4.7 MHz	ASTM D150

Volume Resistivity	1.0X10¹²Ohm-meter	ASTM D257

Fire rating	94 V0	equivalent UL

Thermal conductivity	1.5W/m-K	ASTM D5470

Certifications:

ISO9001:2015

ISO14001: 2004 IATF16949:2016

IECQ QC 080000:2017

Product Thicknesses: 0.020-inch to 0.200-inch (0.5mm to 5.0mm)
Product Sizes: 8" x 16"(203mm x406mm)

Individual die cut shapes and custom thickness can be supplied. Please contact us for confirming.

Popular UL Recognized IATF16949 Thermal Gap Filler Pad 1.5W/MK Good Thermal Conductive For Display Card 0

Advantage

Ziitek has independent R&D team. This team is experience, rigorous and pragmatic.

They undertake the core research and development tasks of Ziitek thermal conductive materials. With well-equipped testing equipment, we Ziitek can also do some tests with customers' samples, so we can find a more suitable Ziitek materials for every customer.

FACTORY INFORMATION:

Factory Size

5,000-10,000 square meters

Factory Country/Region

Building B8, Industry District Ⅱ, Xicheng, Hengli Township, Dongguan City, Guangdong Province, P.R.China

Annual Output Value

US$1 Million - US$2.5 Million
