| Place of Origin: | China |
| Brand Name: | Ziitek |
| Certification: | UL |
| Model Number: | TIF1160-12-05ES thermal pad |
| Minimum Order Quantity: | 1000 pcs |
|---|---|
| Price: | 0.1-10 USD/PCS |
| Packaging Details: | 25*24*13cm canton |
| Delivery Time: | 3-8 work days |
| Payment Terms: | T/T |
| Supply Ability: | 100000pcs/month |
| Hardness: | 12±5 Shore00 | KEYWORD: | Blue Silicone Rubber Pads |
|---|---|---|---|
| Color: | Blue | Part Number: | TIF1160-12-05ES |
| Material: | Silicone | Thickness: | 4.0mmT |
| High Light: | 4.0mmT Thermal Gap Filler,Thermal Gap Filler 1.2W/M-K,1.2W/M-K Silicone Thermal Pads |
||
professional factory thermal gap filler 1.2W/M-K For Set top boxes
Company Profile
Ziitek company is a high-tech enterprise which dedicated to the R&D, manufacture and sales of the thermal interface materials (TIMs). We have rich experiences in this field which can support you the latest, most effective and one -step thermal management solutions. We have many advanced production equipments,full test equipments and fully automatic coating production lines which can support the production for high performance thermal silicone pad, thermal graphite sheet/ film, thermal double-sided tape, thermal insulation pad, thermal ceramic pad, phase change material, thermal grease etc. UL94 V-0, SGS and ROHS are compliant.
TIF100-12-05ES-Series-Datasheet.pdf
<Outstanding thermal performance
<High tack surface reduces contact resistance
<RoHS compliant
<Set top boxes
<Audio and video components
<IT infrastructure
<GPS navigation and other portable devices
<LED TV and LED-lit lamps
<RDRAM memory modules
<Micro heat pipe thermal solutions
|
Typical Properties of TIF1160-12-05ES
|
|||
|
Product Name
|
TIF1160-12-05ES Series
|
||
|
Colour
|
Blue | ||
|
Construction & Compostion
|
Ceramic filled silicone rubber
|
||
|
Density |
2.0 g/cm3
|
||
|
Thickness |
4.0mmT
|
||
|
Hardness
|
12±5 Shore 00
|
||
|
Tensile Strength
|
40 psi
|
||
|
Continuos Use Temp
|
-40to 160℃
|
||
|
Dielectric Breakdown Voltage
|
>5500 VAC
|
||
|
Thermal conductivity
|
1.2 W/mK
|
||
Packaging Details & Lead time
The packaging of thermal pad
1.with PET film or foam-for protection
2. use Paper Card To Separate Each Layer
3. export carton inside and outside
4. meet with customers' requirement-customized
Lead Time :Quantity(Pieces):5000
Est. Time(days): To be negotiated
Standard Sheets Sizes:
8" x 16"(203mm x 406mm)
TIF™ series Individual die cut shapes can be supplied.
| Online-service : 12 hours , Inquiry reply within fastest. |
| Working time: 8:00am - 5:30pm, Monday to Saturday (UTC+8). |
| Well-trained & experienced staff are to answer all your inquiries in English of course. |
| Standard Export Carton Or Marked With Customer's Information Or Customized. |
| Provide free samples |
| After-service: Even our products have passed strict inspection, if you find the parts can not work well, please show us the proof. |
| we will help you to deal with it and give you satisfactory solution. |
FAQ:
Q: Do you accept custom orders ?
A:Yes , welcome to custom orders. Our custom elements including dimension , shape , color and coated on side or two sides adhesive or coated fiberglass. If you want to place a custom order , pls kindly offer a drawing or leave your custom order information .
Q: What kind of packaging you offer?
A: During the packaging process, preventive measures will be taken by us to assure that the goods are in a good condition during storage and delivery.
