Hardness 20 Shore 00 Cpu Thermal Pad Electrically Isolating Silicone For Dvd-Rom Cooling

Hardness 20 Shore 00 Cpu Thermal Pad Electrically Isolating Silicone For Dvd-Rom Cooling

Hardness 20 Shore 00 Cpu Thermal Pad Electrically Isolating Silicone For Dvd-Rom Cooling
video
Hardness 20 Shore 00 Cpu Thermal Pad Electrically Isolating Silicone For Dvd-Rom Cooling
Product Details:
Place of Origin: China
Brand Name: Ziitek
Certification: UL
Model Number: TIF140-32-05US thermal pad
Payment & Shipping Terms:
Minimum Order Quantity: 1000 pcs
Price: 0.1-10 USD/PCS
Packaging Details: 25*24*13cm canton
Delivery Time: 3-8 work days
Payment Terms: T/T
Supply Ability: 100000pcs/month
Contact Now
Detailed Product Description
Keyword: Thermal Gap Pad Name: Hardness 20 Shore 00 Electrically Isolating Silicone Pads For DVD-Rom Cooling
Dielectric Constant: 4.0 MHz Application: IT Infrastructure
Hardness: 20 Shore 00 Certifications: IATF16949
High Light:

dvd-rom cooling cpu thermal pad

,

hardness high cpu thermal pad

Hardness 20 Shore 00 Electrically isolating silicone pads for DVD-Rom cooling



Company Profile

With professional R&D capabilities and over 13 year experiences in thermal interface material industry, Ziitek company own many unique formulations which are our core technologies and advantages. Our goal is to provide quality & competitive products to our customers worldwide aiming for long-term business cooperation.


TIF100-32-05US-Series-Datasheet-REV02.pdf


Ziitek TIF140-32-05US is recommended for applications that require a minimum amount of pressure on components. The viscoelastic nature of the material also gives excellent low-stress vibration dampening and shock absorbing characteristics. Ziitek TIF140-32-05US is an electrically isolating material, which allows its use in applications requiring isolation between heat sinks and high-voltage, bare-leaded devices.




<Good thermal conductive:3.2W/mK
<Thickness:1.0mmT
<Hardness:20 Shore 00
<Colour: blue

<High tack surface reduces contact resistance

<RoHS compliant

<UL recognized


Applications

<Automotive electronics

<Set top boxes

<Audio and video components

<IT infrastructure

<GPS navigation and other portable devices

<CD-Rom, DVD-Rom cooling




Typical Properties of TIF140-32-05US

Product Name

TIF140-32-05US Series

Colour
blue
Construction & Compostion
Ceramic filled silicone elastomer

Specific gravity

3.0 g/cc

Thickness

1.0mmT
Hardness
20 Shore 00
Dielectric constant@1MHz
4.0 MHz
Continuos Use Temp
-40 to 160℃

Dielectric Breakdown Voltage

>5500 VAC
Thermal conductivity
3.2 W/mK
Volume Resistivity

1.0*1012 Ohm-cm




Standard Thicknesses:



0.020" (0.51mm) 0.030" (0.76mm)

0.040" (1.02mm) 0.050" (1.27mm) 0.060" (1.52mm)

0.070" (1.78mm) 0.080" (2.03mm) 0.090" (2.29mm)

0.100" (2.54mm) 0.110" (2.79mm) 0.120" (3.05mm)

0.130" (3.30mm) 0.140" (3.56mm) 0.150" (3.81mm)

0.160" (4.06mm) 0.170" (4.32mm) 0.180" (4.57mm)

0.190" (4.83mm) 0.200" (5.08mm)



Consult the factory to alternate thickness.



Hardness 20 Shore 00 Cpu Thermal Pad Electrically Isolating Silicone For Dvd-Rom Cooling 0





Independent R&D team



Q: How do I place an order?

A:1. Click the "Sent messages" button to continue with the process.

2. Fill out the message form by entering a subject line, and message to us.

This message should include any questions you might have about the products as well as your purchase requests.

3. Click the "Send" button when you are finished to complete the process and send your message to us.

4. We will reply you as soon as possible with Email or online.



Hardness 20 Shore 00 Cpu Thermal Pad Electrically Isolating Silicone For Dvd-Rom Cooling 1

FAQ

Q: Are you trading company or manufacturer ?

A: We are manufacturer in China

Q: How long is your delivery time?

A: Generally it is 3-7 work days if the goods are in stock. or it is 7-10 work days if the goods are not in stock, it is according to quantity.
