Name: Ultra Soft Heat Sink Insulation Pad Thermal Conductivite Gap Filler Pad 3.0mm Thickness
Brand: Dongguan Ziitek Electronical Material and Technology Ltd.
SKU: TIF1120-12-05US thermal pad
Price: 4.10 USD
Availability: InStock

Home Products CPU Thermal Pad

Ultra Soft Heat Sink Insulation Pad Thermal Conductivite Gap Filler Pad 3.0mm Thickness

Product Details:

Place of Origin:	China
Brand Name:	Ziitek
Certification:	UL
Model Number:	TIF1120-12-05US thermal pad

Payment & Shipping Terms:

Minimum Order Quantity:	1000 pcs
Price:	0.1-10 USD/PCS
Packaging Details:	241312cm carton
Delivery Time:	3-8 work days
Payment Terms:	T/T
Supply Ability:	100000pcs/month

Contact Now

Detailed Product Description

Products Name:	Ultra Soft Heat Sink Insulation Pad Thermal Conductivite Gap Filler Pad 3.0mm Thickness	Hardness:	65/20 Shore00
Keywords:	Thermal Conductivite Gap Filler	Color:	Blue
Construction:	Ceramic Filled Silicone Elastomer	Thermal Conductive:	1.2W/mK
Application:	Heat Sink Dissipate Heat
Highlight:	ultra soft heat sink insulation pad , 2.0 g/cc heat sink insulation pad , 3.0 mmt heat sink pad

Ultra Soft Heat Sink Insulation Pad Thermal Conductivite Gap Filler Pad 3.0mm Thickness

Company Profile

Ziitek company is a high-tech enterprise which dedicated to the R&D, manufacture and sales of the thermal interface materials (TIMs). We have rich experiences in this field which can support you the latest, most effective and one -step thermal management solutions. We have many advanced production equipments,full test equipments and fully automatic coating production lines which can support the production for high performance thermal silicone pad, thermal graphite sheet/ film, thermal double-sided tape, thermal insulation pad, thermal ceramic pad, phase change material, thermal grease etc. UL94 V-0, SGS and ROHS are compliant.

Products description

TIF^®1120-12-05US Series is an ultra-soft thermal interface material designed specifically to protect precision components that are extremely sensitive to mechanical stress. This product combines good thermal conductivity with an exceptionally gel-like softness, achieving a low-stress perfect fit.

Features

>Good thermal conductive:1.2W/mK

>Thickness:3.0mmT

>Colour: blue

>High tack surface reduces contact resistance

>RoHS compliant

>UL recognized

Applications

>Notebook

>Power supply

>Heat pipe thermal solutions

>Memory Modules

>Mass storage devices

>Automotive electronics

Typical Properties of TIF^®100-12-05US Series
Property	Value		Test method
Color	Blue		Visual
Construction & Compostion	Ceramic filled silicone elastomer		******
Density(g/cm³)	2.0		ASTM D792
Thickness Range(inch/mm)	0.010~0.020	0.030~0.200	ASTM D374
	(0.25~0.50)	(0.75~5.00)
Hardness	65 Shore 00	20 Shore 00	ASTM 2240
Recommended Operating Temperature	-40 to 200℃		******
Breakdown Voltage(V/mm)	≥5500		ASTM D149
Dielectric Constant	4.5 MHz		ASTM D150
Volume Resistivity	＞1.0X10¹² Ohm-meter		ASTM D257
Flame rating	V-0		UL 94 (E331100)
Thermal conductivity	1.2 W/m-K		ASTM D5470
	1.2 W/m-K		ISO22007

Product Specifications

Standard Thickness: 0.010" (0.25 mm)~0.200" (5.00 mm) with increments of 0.010" (0.25 mm)
Standard Size: 16"×16" (406 mmX406 mm)

Component Codes:
Reinforcement Fabric: FG (Fiberglass).
Coating Options: NS1 (Non-adhesive treatment),
DC1 (Single-sided hardening).
Adhesive Options: A1/A2 (Single-sided/Double-sided adhesive).

The TIF^® series is available in custom shapes and various forms.
For other thicknesses or more information, please contact us.

Our services

Online-service : 12 hours , Inquiry reply within fastest.

Working time: 8:00am - 5:30pm, Monday to Saturday (UTC+8).

Well-trained & experienced staff are to answer all your inquiries in English of course.

Standard Export Carton Or Marked With Customer's Information Or Customized.

Provide free samples

After-service: Even our products have passed strict inspection, if you find the parts can not work well, please show us the proof.

we will help you to deal with it and give you satisfactory solution.

Ultra Soft Heat Sink Insulation Pad Thermal Conductivite Gap Filler Pad 3.0mm Thickness 1
FAQ

Q: How do I place an order?

A:1. Click the "Sent messages" button to continue with the process.

2. Fill out the message form by entering a subject line, and message to us.

This message should include any questions you might have about the products as well as your purchase requests.

3. Click the "Send" button when you are finished to complete the process and send your message to us

4. We will reply you as soon as possible with Email or online.
