| Place of Origin: | China |
| Brand Name: | Ziitek |
| Certification: | UL |
| Model Number: | TIF1180-30-06US thermal pad |
| Minimum Order Quantity: | 1000 pcs |
|---|---|
| Price: | 0.1-10 USD/PCS |
| Packaging Details: | 25*24*13cm canton |
| Delivery Time: | 3-8 work days |
| Payment Terms: | T/T |
| Supply Ability: | 100000pcs/month |
| Hardness: | 18 Shore00 | KEYWORD: | White Silicone Rubber Pads |
|---|---|---|---|
| Color: | White | Part Number: | TIF1180-30-06US |
| Material: | Silicone | Thermal Conductive: | 3.0W/mK |
| High Light: | 4.5mmt thermal conductive silicone pad,led controller thermal conductive silicone pad,4.5mmt thermal pad for cpu |
||
Outstanding thermal performance Available in varies thicknesses silicone pads for LED Controller,4.5mmT
Company Profile
With professional R&D capabilities and over 13 year experiences in thermal interface material industry, Ziitek company own many unique formulations which are our core technologies and advantages. Our goal is to provide quality & competitive products to our customers worldwide aiming for long-term business cooperation.
<RoHS compliant
<UL recognized
<Fiberglass reinforced for puncture, shear and tear resistance
<cooling components to the chassis of frame
<High speed mass storage drives
<Heat Sinking Housing at LED-lit BLU in LCD
<LED TV and LED-lit lamps
<RDRAM memory modules
<Micro heat pipe thermal solutions
|
Typical Properties of TIF1180-30-06US
|
|||
|
Product Name
|
TIF1180-30-06US Series |
||
|
Colour
|
white | ||
|
Construction & Compostion
|
Ceramic filled silicone elastomer
|
||
|
Specific gravity |
3.0 g/cc
|
||
|
Thickness |
4.5mmT
|
||
|
Hardness
|
18 Shore 00
|
||
|
Dielectric constant@1MHz
|
4.0 MHz
|
||
|
Continuos Use Temp
|
-40to 160℃
|
||
|
Dielectric Breakdown Voltage
|
>5500 VAC
|
||
|
Thermal conductivity
|
3.0 W/mK
|
||
| Volume Resistiviyt |
1.0*1012 Ohm-cm |
||
Packaging Details & Lead time
The packaging of thermal pad
1.with PET film or foam-for protection
2. use Paper Card To Separate Each Layer
3. export carton inside and outside
4. meet with customers' requirement-customized
Lead Time :Quantity(Pieces):5000
Est. Time(days): To be negotiated
Ziitek Culture
Quality :
Do it right the first time, total quality control
Effectiveness:
Work precisely and thoroughly for effectiveness
Service:
Quick response, On time delivery and Excellent service
Team work:
Complete teamwork, including sales team, Marketing team, engineering team, R&D team, Manufacturing team, logistics team. All is for supporting and servicing a satisfy service for customers.
FAQ
Q: Do you provide samples ? is it free or extra cost?
A: Yes, we could offer samples free of charge
Q: Do you offer free samples ?
A: Yes, we are willing to offer free sample.
Contact Person: Miss. Dana
Tel: +86 18153789196
