Name: 5.0W/MK Good Heat Dissipation Thermal Pad Battery Thermal Pad Thermal Pads For EV Batteries Protection
Brand: Dongguan Ziitek Electronical Material and Technology Ltd.
SKU: TIF100C 5045-11
Price: 4.10 USD
Availability: InStock

Home Products Silicone Thermal Pad

5.0W/MK Good Heat Dissipation Thermal Pad Battery Thermal Pad Thermal Pads For EV Batteries Protection

Product Details:

Place of Origin:	China
Brand Name:	Ziitek
Certification:	UL & RoHS
Model Number:	TIF100C 5045-11

Payment & Shipping Terms:

Minimum Order Quantity:	1000pcs
Price:	0.1-10 USD/PCS
Packaging Details:	241312cm cartons
Delivery Time:	3-5 work days
Payment Terms:	T/T
Supply Ability:	1000000 pcs/month

Contact Now

Detailed Product Description

Products Name:	5.0W/MK Good Heat Dissipation Thermal Pad Battery Thermal Pad Thermal Pads For EV Batteries Protection	Hardness:	45 Shore 00
Thermal Conductivity:	5.0W/mK	Color:	Gray
Flam Rating:	94 V-0	Thinkness Range:	0.012"(0.30mm)~0.200"(5.00mm)
Certification:	RoHS And UL Recognized	Application:	EV Batteries
Keywords:	Thermal Pads
Highlight:	5.0W/MK Thermal Pad , EV Batteries Protection Thermal Pad , Battery Thermal Pad

5.0W/MK Good Heat Dissipation Thermal Pad Battery Thermal Pad Thermal Pads For EV Batteries Protection

Company Profile

Ziitek company is a high-tech enterprise which dedicated to the R&D, manufacture and sales of the thermal interface materials (TIMs). We have rich experiences in this field which can support you the latest, most effective and one -step thermal management solutions. We have many advanced production equipments,full test equipments and fully automatic coating production lines which can support the production for high performance thermal silicone pad, thermal graphite sheet/ film, thermal double-sided tape, thermal insulation pad, thermal ceramic pad, phase change material, thermal grease etc. UL94 V-0, SGS and ROHS are compliant.

Certifications:

ISO9001:2015

ISO14001: 2004 IATF16949:2016

IECQ QC 080000:2017

TS-TIF^®100C 5040-11 series is a silicone-based thermal material designed to fill the gaps between heat-generating components and liquid cooling plates or metal bases.lts flexibility and elasticity make it ideal for covering highly uneven surfaces.With excellent thermal conductivity, it efficiently transfers heat from heat-generating elements or PCBs to liquid cooling plates or metal heat dissipation structures, thereby improving the cooling efficiency of high-power electronic components and extending the lifespan of the equipment.

Features:

> Excellent thermal conductivity 5.0W/mK

> Self-adhesive without the need for additional surface adhesive
> Highly compressible, soft, and elastic

> Available in various thicknesses
> Good chemical stability

Applications:

> CPU and GPU processors and other chipsets
> Cooling components to the chassis of frame
> High speed mass storage drives
> Heat Sinking Housing at LED-lit BLU in LCD
> LED TV and LED-lit lamps
> RDRAM memory modules

> New energy vehicles

Typical Properties of TS-TIF^®100C 5045-11 Series
Color	Gray	Visual
Construction & Compostion	Ceramic filled silicone elastomer	******
Specific Gravity	3.2g/cc	ASTM D297
thickness	0.012"(0.30mm)~0.200"(5.00mm)	ASTM D374
Hardness (thickness＜1.0mm)	45(Shore 00)	ASTM 2240
Continuos Use Temp	-45 to 200℃	******
Dielectric Breakdown Voltage	≥5500 VAC	ASTM D149
Dielectric Constant	6.0MHz	ASTM D150
Volume Resistivity	≥1.0X10¹²Ohm-meter	ASTM D257
Fire rating	94 V0	equivalent UL
Thermal conductivity	5.0W/m-K	ASTM D5470

Standard Thicknesses:

0.020" (0.51mm) 0.030" (0.76mm)

0.040" (1.02mm) 0.050" (1.27mm) 0.060" (1.52mm)

0.070" (1.78mm) 0.080" (2.03mm) 0.090" (2.29mm)

0.100" (2.54mm) 0.110" (2.79mm) 0.120" (3.05mm)

0.130" (3.30mm) 0.140" (3.56mm) 0.150" (3.81mm)

0.160" (4.06mm) 0.170" (4.32mm) 0.180" (4.57mm)

0.190" (4.83mm) 0.200" (5.08mm)

Consult the factory to alternate thickness.

Product Specification
Product Thicknesses: 0.012"(0.30mm)-0.200"(5.00mm)

Product Sizes:8" x 16"(203mm x406mm)
Custom die-cut shapes and thicknesses are available.Please contact us for details.
Store in a cool, dry place, away from fire and sunlight.

5.0W/MK Good Heat Dissipation Thermal Pad Battery Thermal Pad Thermal Pads For EV Batteries Protection 0

Packaging Details & Lead time

The packaging of thermal pad

1.with PET film or foam-for protection

2. use Paper Card To Separate Each Layer

3. export carton inside and outside

4. meet with customers' requirement-customized

Lead Time :Quantity(Pieces):5000

Est. Time(days): To be negotiated.

FAQ:

Q: Are you trading company or manufacturer ?

A: We are manufacturer in China.

Q: How long is your delivery time?

A: Generally it is 3-7 work days if the goods are in stock. or it is 7-10 work days if the goods are not in stock, it is according to quantity.

Q: Do you offer free samples ?

A: Yes, we are willing to offer free sample.
