Silicone 2.0 W/MK Thermal Conductive Pads Heatsink For Audio And Video Components

Silicone 2.0 W/MK Thermal Conductive Pads Heatsink For Audio And Video Components

Silicone 2.0 W/MK Thermal Conductive Pads Heatsink For Audio And Video Components
video
Silicone 2.0 W/MK Thermal Conductive Pads Heatsink For Audio And Video Components
Product Details:
Place of Origin: China
Brand Name: Ziitek
Certification: UL
Model Number: TIF1180-20-10UF thermal pad
Payment & Shipping Terms:
Minimum Order Quantity: 1000 pcs
Price: 0.1-10 USD/PCS
Packaging Details: 25*24*13cm canton
Delivery Time: 3-8 work days
Payment Terms: T/T
Supply Ability: 100000pcs/month
Contact Now
Detailed Product Description
Material: Silicone Application: Video Components
Keyword: Thermal Gap Pad Name: -40 To 160℃ Easy Release Construction Silicone Pads For Audio And Video Components
Dielectric Breakdown Voltage: >5500 VAC Specific Gravity: 2.7 G/cc
Highlight:

Video Components thermal conductive pads heatsink

,

2.0 W/mK thermal conductive pads heatsink

,

4.5mm thermally conductive interface pads

-40 to 160℃ Easy Release Construction Silicone Pads for Audio and Video Components



Company Profile

With a wide range, good quality, reasonable prices and stylish designs, Ziitek thermal conductive interface materials are extensively used in Mainboards, VGA cards, Notebooks, DDR&DDR2 products, CD-ROM ,LCD TV, PDP products, Server Power products, Down lamps, Spotlights, Street lamps, Daylight lamps, LED Server Power products and others.



TIF100-20-10UF-Datasheet-REV02.pdf



Ziitek TIF1180-20-10UF is a silicone based, thermally conductive gap pad. Its unreinforced construction allows additional compliancy. This product has low hardness is conformable and is electrically isolating. The low modulus characteristic of the product offers optimal thermal performance with the ease of handling.




<Good thermal conductive: 2.0 W/mK
<Thickness: 4.5mmT
<Hardness:75 Shore 00
<Colour: gray

<Easy release construction
<Electrically isolating
<High durability








Applications

<Automotive electronics

<Set top boxes

<Audio and video components

<IT infrastructure

<GPS navigation and other portable devices

<CD-Rom, DVD-Rom cooling



Typical Properties of TIF1180-20-10UF

Product Name TIF1180-20-10UF Series
Colour Gray
Construction & Compostion Ceramic filled silicone elastomer
Specific gravity 2.7 g/cc
Thickness 4.5mmT
Hardness 75 Shore 00
Dielectric constant@1MHz 4.6 MHz
Continuos Use Temp -40 to 160℃
Dielectric Breakdown Voltage >5500 VAC
Thermal conductivity 2.0W/mK
Volume Resistivity 1.0*1012 Ohm-cm



Certifications:

ISO9001:2015

ISO14001: 2004 IATF16949:2016

IECQ QC 080000:2017

UL



Silicone 2.0 W/MK Thermal Conductive Pads Heatsink For Audio And Video Components 0




Our services



Online-service : 12 hours , Inquiry reply within fastest.


Working time: 8:00am - 5:30pm, Monday to Saturday (UTC+8).

Well-trained & experienced staff are to answer all your inquiries in English of course.

Standard Export Carton Or Marked With Customer's Information Or Customized.

Provide free samples



After-service: Even our products have passed strict inspection, if you find the parts can not work well, please show us the proof.

we will help you to deal with it and give you satisfactory solution.





Silicone 2.0 W/MK Thermal Conductive Pads Heatsink For Audio And Video Components 1

FAQ

Q: What kind of packaging you offer?

A: During the packaging process, preventive measures will be taken by us to assure that the goods are in a good condition during storage and delivery.

Q:Do big buyers have promotional prices?

A: Yes, if you are a big buyer in a certain area, Ziitek will provide you with promotional prices, which will help you start your business here. Buyers with long-term cooperation will have better prices.
