4.0mmT Soft And Compressible For Low Stress Applications Silicone Pads For LED Power

4.0mmT Soft And Compressible For Low Stress Applications Silicone Pads For LED Power

4.0mmT Soft And Compressible For Low Stress Applications Silicone Pads For LED Power
video
4.0mmT Soft And Compressible For Low Stress Applications Silicone Pads For LED Power
Product Details:
Place of Origin: China
Brand Name: Ziitek
Certification: UL
Model Number: TIF1160N-50-10F thermal pad
Payment & Shipping Terms:
Minimum Order Quantity: 1000 pcs
Price: 0.1-10 USD/PCS
Packaging Details: 25*24*13cm canton
Delivery Time: 3-8 work days
Payment Terms: T/T
Supply Ability: 100000pcs/month
Contact Now
Detailed Product Description
Name: 4.0mmT Soft And Compressible For Low Stress Applications Silicone Pads For LED Power Flame Rating: 94-V0
Keyword: Thermal Gap Pad Thickness: 4.0mmT
Hardness: 55±5 Shore 00 Application: Mainboard/mother Board
High Light:

4.0mm Thickness Silicone Pads

,

LED Power Silicone Pads

,

LED Silicone Heat Sink Pad

4.0mmT Soft and Compressible for Low Stress Applications Silicone Pads for LED Power



Company Profile

Ziitek Electronic Material and Technology Ltd. is a R&D and production company, we have many production lines and processing technology of thermal conductive materials, owns advanced production equipment and optimized process, can provide various thermal solutions for different applications.



TIF100N-50-10F-Specification-sheet.pdf



Ziitek TIF1160N-50-10F is a silicone based, thermally conductive gap pad. Its unreinforced construction allows additional compliancy. This product has low hardness is conformable and is electrically isolating. The low modulus characteristic of the product offers optimal thermal performance with the ease of handling.




<Good thermal conductive: 5.0 W/mK
<Thickness: 4.0mmT
<Hardness:55±5 Shore 00
<Colour: gray

<Moldability for complex parts
<Soft and compressible for low stress applications
<Naturally tacky needing no further adhesive coating









Applications

<LED Power Supply

<LED Controller

<LED Ceilinglamp

<Monitoring the Power Box

<AD-DC Power Adapters

<Rainproof LED Power






Typical Properties of TIF1160N-50-10F

Product Name TIF1160N-50-10F Series
Colour Gray
Construction & Compostion Ceramic filled silicone elastomer
Specific gravity

2.1 g/cm^3

Thickness 4.0mmT
Hardness 55±5 Shore 00
Dielectric constant@1MHz 4.7 MHz
Continuos Use Temp -40 to 160℃
Dielectric Breakdown Voltage >5500 VAC
Thermal conductivity 5.0W/mK
Flame Rating 94-V0




Packaging Details & Lead time



The packaging of thermal pad

1.with PET film or foam-for protection

2. use Paper Card To Separate Each Layer

3. export carton inside and outside

4. meet with customers' requirement-customized



Lead Time :Quantity(Pieces):5000

Est. Time(days): To be negotiated





4.0mmT Soft And Compressible For Low Stress Applications Silicone Pads For LED Power 0







Independent R&D team



Q: How do I place an order?

A:1. Click the "Sent messages" button to continue with the process.

2. Fill out the message form by entering a subject line, and message to us.

This message should include any questions you might have about the products as well as your purchase requests.

3. Click the "Send" button when you are finished to complete the process and send your message to us

4. We will reply you as soon as possible with Email or online



4.0mmT Soft And Compressible For Low Stress Applications Silicone Pads For LED Power 1

FAQ

Q: Do you accept custom orders ?

A:Yes , welcome to custom orders. Our custom elements including dimension , shape , color and coated on side or two sides adhesive or coated fiberglass. If you want to place a custom order , pls kindly offer a drawing or leave your custom order information .

Q: How much are the pads?

A: Price is depended on your size, thickness, quantity, and other requirements, such as adhesive and others. Please let us know these factors first so that we could give you an exact price.
