Specific Gravity 2.8 g/cm^3 Good Thermal Conductive Heat Sink Pad for Routers

Specific Gravity 2.8 g/cm^3 Good Thermal Conductive Heat Sink Pad for Routers

Specific Gravity 2.8 g/cm^3 Good Thermal Conductive Heat Sink Pad for Routers
video
Specific Gravity 2.8 g/cm^3 Good Thermal Conductive Heat Sink Pad for Routers
Product Details:
Place of Origin: China
Brand Name: Ziitek
Certification: UL
Model Number: TIF2120-20-02ES thermal pad
Payment & Shipping Terms:
Minimum Order Quantity: 1000 pcs
Price: 0.1-10 USD/PCS
Packaging Details: 25*24*13cm canton
Delivery Time: 3-8 work days
Payment Terms: T/T
Supply Ability: 100000pcs/month
Contact Now
Detailed Product Description
Name: Specific Gravity 2.8 G/cm^3 Good Thermal Conductive Heat Sink Pad For Routers Thermal Conductive: 2.0 W/mK
Keyword: Thermal Gap Pad Colour: Pink/White
Hardness: 10 Shore 00 Dielectric Constant@1MHz: 5.0 MHz
High Light:

Thermal Conductive Heat Sink Pad

,

Routers Heat Sink Pad

,

2.8g/cm3 Heat Sink Thermal Pad

Specific Gravity 2.8 g/cm^3 Good Thermal Conductive Heat Sink Pad for Routers



Company Profile

Ziitek Electronic Material and Technology Ltd. provides product solutions to equipment product which generates too much heat affecting its high performance when using. Plus thermal products can control and manage heat to keep it cool to some extent.



TIF200-20-02ES-Series-Datasheet.pdf



Ziitek TIF2120-20-02ES is not only designed to take advantage of the gap heat transfer, to fill gaps, complete the heat transfer between heating and cooling parts, but also played insulation, damping, sealing and so on, to meet the equipment miniaturization and ultra-thin design Requirements, which is a highly technology and use, and the thickness of the wide range of applications, is also an excellent thermal conductivity filler material.




<Good thermal conductive: 2.0 W/mK
<Thickness: 3.0mmT
<Hardness:10 Shore 00
<Colour: Pink/White

<Good thermal conductive
<Moldability for complex parts
<Soft and compressible for low stress applications













Applications

<Waterproof LED Power

<SMD LED module

<LED Flesible strip, LED bar

<LED PanelLight

<LED floor light

<Routers






Typical Properties of TIF2120-20-02ES

Product Name TIF2120-20-02ES Series
Colour Pink/White
Construction & Compostion Ceramic filled silicone elastomer
Specific gravity

2.8 g/cm^3

Thickness 3.0mmT
Hardness 10 Shore 00
Dielectric constant@1MHz 5.0 MHz
Continuos Use Temp -40 to 160℃
Dielectric Breakdown Voltage >5000 VAC
Thermal conductivity 2.0W/mK
Flame Rating 94-V0




Packaging Details & Lead time



The packaging of thermal pad

1.with PET film or foam-for protection

2. use Paper Card To Separate Each Layer

3. export carton inside and outside

4. meet with customers' requirement-customized



Lead Time :Quantity(Pieces):5000

Est. Time(days): To be negotiated





Specific Gravity 2.8 g/cm^3 Good Thermal Conductive Heat Sink Pad for Routers 0
