Good Performance And Insulation Heat Sink Pad For Mass Storage Devices 4.5 MHz

Good Performance And Insulation Heat Sink Pad For Mass Storage Devices 4.5 MHz

Good Performance And Insulation Heat Sink Pad For Mass Storage Devices 4.5 MHz
video
Good Performance And Insulation Heat Sink Pad For Mass Storage Devices 4.5 MHz
Product Details:
Place of Origin: China
Brand Name: Ziitek
Certification: UL
Model Number: TIF7160HM thermal pad
Payment & Shipping Terms:
Minimum Order Quantity: 1000 pcs
Price: 0.1-10 USD/PCS
Packaging Details: 25*24*13cm canton
Delivery Time: 3-8 work days
Payment Terms: T/T
Supply Ability: 100000pcs/month
Contact Now
Detailed Product Description
Thickness: 4.0mmT Name: Good Performance And Insulation Heat Sink Pad For Mass Storage Devices, 4.5 MHz
Hardness: 45±5 Shore 00 Specific Gravity: 3.3 G/cm^3
Keyword: Thermal Gap Pad Part Number: TIF7160HM
Highlight:

Storage Devices Heat Sink Pad

,

Heat Sink Pad 4.5 MHz

,

4.0mm Heat Sink Thermal Pad

Good Performance And Insulation Heat Sink Pad For Mass Storage Devices, 4.5 MHz



Company Profile

Ziitek company is a manufacturer of thermal conductive gap fillers, low melting point thermal interface materials, thermal conductive insulators, thermally conductive tapes, electrically & thermally conductive Interface pads and thermal grease,Thermal Conductive plastic,Silicone Rubber,Silicone Foams,Phase Changing Materials products, with well-equipped testing equipment and strong technical force.



TIF700HM-Series-Datasheet.pdf



Ziitek TIF7160HM is not only designed to take advantage of the gap heat transfer, to fill gaps, complete the heat transfer between heating and cooling parts, but also played insulation, damping, sealing and so on, to meet the equipment miniaturization and ultra-thin design Requirements, which is a highly technology and use, and the thickness of the wide range of applications, is also an excellent thermal conductivity filler material.




< Good thermal conductive: 6.0 W/mK
< Thickness: 4.0mmT
< Hardness: 45±5 Shore 00
< Colour: Grey

<Moldability for complex parts
<Outstanding thermal performance
<High tack surface reduces contact resistance













Applications

<mainboard/mother board

<notebook

<power supply

<Heat pipe thermal solutions

<Memory Modules

<Mass storage devices




Typical Properties of TIF7160HM

Product Name TIF7160HM Series
Colour Grey
Construction & Compostion Ceramic filled silicone elastomer
Specific gravity

3.3 g/cm3

Thickness 4.0mmT
Hardness 45±5 Shore 00
Dielectric constant@1MHz 4.5 MHz
Continuos Use Temp -40 to 160℃
Dielectric Breakdown Voltage >5500 VAC
Thermal conductivity 6.0W/mK
Flame Rating 94-V0




Standard Sheets Sizes:

8" x 16"(203mm x 406mm)



TIF™ series Individual die cut shapes can be supplied.



Good Performance And Insulation Heat Sink Pad For Mass Storage Devices 4.5 MHz 0






Why Choose us ?

1.Our value message is'' Do it right the First time, total quality control''.
2.Our core competencies is thermal conductive interface materials
3.Competitive advantage products.
4.Condidentiality agreement Bussiness Secrect Contract
5.Free sample offer
6.Quality assurance contract





Good Performance And Insulation Heat Sink Pad For Mass Storage Devices 4.5 MHz 1

FAQ

Q: What kind of packaging you offer?

A: During the packaging process, preventive measures will be taken by us to assure that the goods are in a good condition during storage and delivery.

Q:Do big buyers have promotional prices?

A: Yes, if you are a big buyer in a certain area, Ziitek will provide you with promotional prices, which will help you start your business here. Buyers with long-term cooperation will have better prices.
