| Place of Origin: | China |
| Brand Name: | Ziitek |
| Certification: | UL |
| Model Number: | TIF7100HZ thermal pad |
| Minimum Order Quantity: | 1000 pcs |
|---|---|
| Price: | 0.1-10 USD/PCS |
| Packaging Details: | 25*24*13cm canton |
| Delivery Time: | 3-8 work days |
| Payment Terms: | T/T |
| Supply Ability: | 100000pcs/month |
| Name: | Thermal Conductive Silicone Hot Pad For Led Computer Graphics Card Cpu Gpu | Thickness: | 2.5mmT |
|---|---|---|---|
| Specific Gravity: | 3.45 G/cm^3 | Part Number: | TIF7100HZ |
| Hardness: | 55±5 | Keyword: | Silicone Hot Pad |
| High Light: | Cpu Gpu Silicone Hot Pad,Thermal Conductive Silicone Hot Pad,Gpu Thermal Conductive Silicone Pad |
||
Thermal Conductive Silicone Hot Pad For Led Computer Graphics Card Cpu Gpu
Company Profile
With professional R&D capabilities and over 18 year experiences in thermal interface material industry, Ziitek company own many unique formulations which are our core technologies and advantages. Our goal is to provide quality & competitive products to our customers worldwide aiming for long-term business cooperation.
TIF700HZ-Series-Datahseet.pdf
Ziitek TIF7100HZ is an extremely soft gap filling material rated at a thermal conductivity of 7W/m-K. It is specially formulated for high performance applications requiring low assembly stress. The material offers exceptional thermal performance at low pressures due to the unique filler package and ultra low modulus resin formulation. Ziitek TIF7100HZ is highly conformal to rough or irregular surfaces, allowing excellent wet-out at the interface. Protective liners are supplied on both sides allowing for ease of use.
< Good thermal conductive
< Moldability for complex parts
< Soft and compressible for low stress applications
> AD-DC Power Adapters
> Rainproof LED Power
> Waterproof LED Power
> SMD LED module
> LED Flesible strip, LED bar
> LED PanelLight
|
Typical Properties of TIF7100HZ
|
|||
| Product Name | TIF7100HZ Series | ||
| Colour | Blue | ||
| Construction & Compostion | Ceramic filled silicone elastomer | ||
| Specific gravity |
3.45 g/cc |
||
| Thickness | 2.5mmT | ||
| Hardness | 55±5 | ||
| Dielectric constant@1MHz | 4.5 MHz | ||
| Continuos Use Temp | -40 to 160℃ | ||
| Dielectric Breakdown Voltage | >5500 VAC | ||
| Thermal conductivity | 7.0W/mK | ||
| Flame Rating | 94-V0 | ||
Packaging Details & Lead time
The packaging of thermal pad
1.with PET film or foam-for protection
2. use Paper Card To Separate Each Layer
3. export carton inside and outside
4. meet with customers' requirement-customized
Lead Time :Quantity(Pieces):5000
Est. Time(days): To be negotiated
Independent R&D team
Q: How do I place an order?
A:1. Click the "Sent messages" button to continue with the process.
2. Fill out the message form by entering a subject line, and message to us.
This message should include any questions you might have about the products as well as your purchase requests.
3. Click the "Send" button when you are finished to complete the process and send your message to us
4. We will reply you as soon as possible with Email or online
FAQ
Q: Are you trading company or manufacturer ?
A: We are manufacturer in China.
Q: How long is your delivery time?
A: Generally it is 3-7 work days if the goods are in stock. or it is 7-10 work days if the goods are not in stock, it is according to quantity.
