Name: Thermal Interface Material Thermal Silicone Pad For New Energy Vehicle Batteries PCB
Brand: Dongguan Ziitek Electronical Material and Technology Ltd.
SKU: TIF740PUS thermal pad
Price: 4.10 USD
Availability: InStock

Home Products Heat Sink Thermal Pad

Thermal Interface Material Thermal Silicone Pad For New Energy Vehicle Batteries PCB

Product Details:

Place of Origin:	China
Brand Name:	Ziitek
Certification:	UL
Model Number:	TIF740PUS thermal pad

Payment & Shipping Terms:

Minimum Order Quantity:	1000 pcs
Price:	0.1-10 USD/PCS
Packaging Details:	252413cm canton
Delivery Time:	3-8 work days
Payment Terms:	T/T
Supply Ability:	100000pcs/month

Contact Now

Detailed Product Description

Name:	China Wholesale Thermal Interface Material Pads Thermal Silicone Pad For New Energy Vehicle Batteries PCB	Specific Gravity:	3.2 G/cm³
Hardness:	20	Thickness:	1.0 MmT
Part Number:	TIF740PUS	Keyword:	Thermal Interface Material Pads
Highlight:	China Wholesale Thermal Interface Material Pads , PCB Thermal Interface Material Pads , Vehicle Batteries Thermal Silicone Pad

China Wholesale Thermal Interface Material Pads Thermal Silicone Pad for New Energy Vehicle Batteries PCB

Company Profile

Ziitek company is a manufacturer of thermal conductive gap fillers, low melting point thermal interface materials, thermal conductive insulators, thermally conductive tapes, electrically & thermally conductive Interface pads and thermal grease,Thermal Conductive plastic,Silicone Rubber,Silicone Foams,Phase Changing Materials products, with well-equipped testing equipment and strong technical force.

TIF700PUS-data sheet.pdf

Thermal Interface Material Thermal Silicone Pad For New Energy Vehicle Batteries PCB 0

Ziitek TIF740PUS use a special process, with silicone as the base material, adding thermal conductive powder and flame retardant together to make the mixture to become thermal interface material. This is effective in lower the thermal resistance between the heat source and the heat sink.

< Good thermal conductive: 7.5W/mK

< Thickness: 1.0mmT

< Hardness: 20

< Colour: gray

< Moldability for complex parts
< Outstanding thermal performance
< High tack surface reduces contact resistance

Applications

> LED floor light
> Routers
> Cooling components to the chassis of frame
> High speed mass storage drives
> Heat Sinking Housing at LED-lit BLU in LCD

Typical Properties of TIF740PUS
Product Name	TIF740PUS Series
Colour	Gray
Construction & Compostion	Ceramic filled silicone elastomer
Specific gravity	3.2 g/cc
Thickness	1.0 mmT
Hardness(Shore 00)	20
Dielectric constant@1MHz	4.5 MHz
Continuos Use Temp	-40 to 160℃
Dielectric Breakdown Voltage	>6000 VAC
Thermal conductivity	7.5W/mK
Flame Rating	94-V0

Standard Thicknesses:

0.020" (0.51mm) 0.030" (0.76mm)

0.040" (1.02mm) 0.050" (1.27mm) 0.060" (1.52mm)

0.070" (1.78mm) 0.080" (2.03mm) 0.090" (2.29mm)

0.100" (2.54mm) 0.110" (2.79mm) 0.120" (3.05mm)

0.130" (3.30mm) 0.140" (3.56mm) 0.150" (3.81mm)

0.160" (4.06mm) 0.170" (4.32mm) 0.180" (4.57mm)

0.190" (4.83mm) 0.200" (5.08mm)

Consult the factory to alternate thickness.

Ziitek Culture

Quality :

Do it right the first time, total quality control

Effectiveness:

Work precisely and thoroughly for effectiveness

Service:

Quick response, On time delivery and Excellent service

Team work:

Complete teamwork, including sales team, Marketing team, engineering team, R&D team, Manufacturing team, logistics team. All is for supporting and servicing a satisfy service for customers.

FAQ

Q: Are you trading company or manufacturer ?

A: We are manufacturer in China

Q: What kind of packaging you offer?

A: During the packaging process, preventive measures will be taken by us to assure that the goods are in a good condition during storage and delivery.
