Name: High Performance One Component Thermal Conductivity Epoxy Glue For Electronic Potting Compound
Brand: Dongguan Ziitek Electronical Material and Technology Ltd.
SKU: TIE™380-25
Price: 50.00 USD
Availability: InStock

Home Products Thermal Epoxy Glue

High Performance One Component Thermal Conductivity Epoxy Glue For Electronic Potting Compound

Product Details:

Place of Origin:	China
Brand Name:	Ziitek
Certification:	RoHS
Model Number:	TIE™380-25

Payment & Shipping Terms:

Minimum Order Quantity:	10kg
Price:	1-100USD/kg
Packaging Details:	1kg/can
Delivery Time:	3-8 work days
Payment Terms:	T/T
Supply Ability:	10000kg/month

Contact Now

Detailed Product Description

Products Name:	High Performance One Component Thermal Conductivity Epoxy Glue For Electronic Potting Compound	Material:	Epoxy Glue
Usage:	Bonding Electronics	Appearance Sured:	Dull Gray Solid
Continuous Use Temp:	-40 To 180℃	Thermal Conductivity:	2.5 W/mK
Keywords:	Thermal Epoxy Glue
Highlight:	One Component Thermal Epoxy Glue , Electronic Potting Compound Thermal Epoxy Glue , High Performance Thermal Epoxy Glue

High Performance One Component Thermal Conductivity Epoxy Glue for electronic potting compound

Product Summary:

TIE^TM380-25 is a one component, heat cured epoxy adhesive. lt has excellent thermal conductivity and bond strength.

TIE^TM380-25 is a good choice for high speed production lines because it has the rheology to allow stencil printing and a fast, one component, heat cure.

Spec-of-TIE380-25.pdf

High Performance One Component Thermal Conductivity Epoxy Glue For Electronic Potting Compound 0

Feature

> Outstanding thermal performance 2.5W/mK
> High tack surface reduces contact resistance
> RoHS compliant
> UL recognized
> Fiberglass reinforced for puncture, shear and tear resistance
> Easy release construction

Applications

> Waterproof LED Power
> SMD LED module
> LED Flesible strip, LED bar
> LED Panel Light
> LED floor light
> Routers

Typical Properties of TIE^TM380-25
Chemical type	Epoxy	Test Method
Appearance uncured	Gray Paste	Visual
Appearance cured	Dull Gray Solid	Visual
Components	One Component	*****
Heat Capacity	0.7 l/g-K	ASTM C351
Key Substrates	Metals, ceramics	*****
Hardness	92 Shore A	ASTM 2240
Continuous Use Temp	-40 to 180℃	*****
Tensile strength Al/Al @25°C	>2800psi	*****
Thermal Conductivity	2.5 W/m-K	ASTM D5470
Packing details	1kg/can	*****

Application Features:TIE™380-25

Color Gray

Viscosity@25℃ 140,000 cPs

Specific Gravity@25℃ 2.1 g/cc

Shelf life @25℃° 10 Days

@0℃° 6 Months

(Storage methods and temperature will affect the shelf life)

Curing procedures:

Curing temperature Curing time

100℃° 3 Hours

125℃ 1.5 Hour

150℃ 20 Minutes

170℃ 5 Minutes
