Good Process Compatibility 7.5W/mK Thermal Conductive Phase Change Material For Payload Processor

Product Details:

Place of Origin:	China
Brand Name:	Ziitek
Certification:	RoHS
Model Number:	TIC800H
Document:	TIC800H_Data Sheet .pdf

Payment & Shipping Terms:

Minimum Order Quantity:	1000pcs
Price:	0.1-10 USD/PCS
Packaging Details:	241312cm carton
Delivery Time:	3-6 work days
Payment Terms:	T/T
Supply Ability:	1000000 pcs/month

Contact Now

Detailed Product Description

Products Name:	Good Process Compatibility 7.5W/mK Thermal Conductive Phase Change Material For Payload Processor	Keyword:	Phase Change Material
Applicatoin:	Payload Processor	Density:	2.7 G/cm³
Thermal Conductivity:	7.5W/mK	Phase Change Softening Temperature(℃):	50℃~60℃
Recommended Operating Temperature (℃):	-40~125℃	Color:	Gray

Good Process Compatibility 7.5W/mK Thermal Conductive Phase Change Material For Payload Processor

Company profile

Dongguan Ziitek Electronic Material and Technology Ltd. is a professional manufacturer of thermal interface materials with many years of industry experience. Integrating R&D, production, sales, and technical services, the company offers a comprehensive product line covering thermally conductive silicone pads, thermal conductive grease/paste,thermally conductive graphite sheets, phase change materials, thermally conductive plastics, thermal gel , silicone foam, silicone-free thermal pads etc.We adhere to strict quality standards and provide customized solutions based on customer requirements. Our products are widely used in electronics, new energy, telecommunications, industrial control, and other fields, earning the trust of customers both domestically and internationally through our proven capabilities.

Products decsription

The TIC^®800H Series is an ultra-high thermal conductivity phase change material with a unique grain orientation structure. This structure achieves directional optimization of the heat flow path through micro ordered arrangement, significantly doubling the macroscopic thermal conductivity efficiency. When the temperature exceeds the phase transition point of 50℃, the material can soften and infiltrate the interface, filling micro irregular gaps, and ultimately forming a heat conduction channel with extremely low thermal resistance at the contact surface, improving the eficiency of the heat dissipation system.

Features

> Excellent thermal conductivity
> Good process compatibility
> Soft surface and self adhesive
> Low steady-state thermal resistance

Applications

> Power conversion equipment
> Payload processor
> Server CPU
> Game graphics card GPU chip heat dissipation

Typical Properties of TIC^®800H Series
Product Name	TIC^®808H	TIC^®810H	TIC^®812H	Testing standards
Color	Gray			Visual
Thickness(inch/mm)	0.008"	0.010"	0.012"	ASTM D374
Thickness(inch/mm)	(0.20mm)	(0.25mm)	(0.30mm)	ASTM D374
Density(g/cm³)	2.7			ASTM D792
Recommended Operating Temperature (℃)	-40～125			-
Phase Change Softening Temperature(℃)	50~60			-
Thermal conductivity	7.5 W/mK			ASTM D5470
Thermal lmpedance (℃-in²/W)@10 psi	0.018	0.019	0.021	ASTM D5470
Thermal lmpedance (℃-in²/W)@50 psi	0.013	0.014	0.015	ASTM D5470

Product Specifications
Standard Thickness:0.008" (0.20 mm),0.010" (0.25 mm),0.012" (0.30 mm)
Standard Size: 10" x 16" (254 mm x 406 mm)

TIC^®series can be molded into different shapes to provide. If you need different thicknesses or would like to learn more about thermal conductive materials, please contact our company.

Independent R&D team

Q: How do I place an order?

A:1. Click the "Sent messages" button to continue with the process.

2. Fill out the message form by entering a subject line, and message to us.

This message should include any questions you might have about the products as well as your purchase requests.

3. Click the "Send" button when you are finished to complete the process and send your message to us.

4. We will reply you as soon as possible with Email or online.

FAQ:

Q: Are you trading company or manufacturer ?

A: We are manufacturer in China

Q: How long is your delivery time?

A: Generally it is 3-7 work days if the goods are in stock. or it is 7-10 work days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra cost?

A: Yes, we could offer samples free of charge.
