High performance low cost CPU thermal pad TIF100-12U with blue color for various electronic device

High performance low cost CPU thermal pad TIF100-12U with blue color for various electronic device

High performance low cost CPU thermal pad TIF100-12U with blue color for various electronic device
video
High performance low cost CPU thermal pad TIF100-12U with blue color for various electronic device
Product Details:
Place of Origin: China
Brand Name: Ziitek
Certification: UL
Model Number: TIF100-12U thermal pad
Payment & Shipping Terms:
Minimum Order Quantity: 1000 pcs
Price: 0.1-10 USD/PCS
Packaging Details: 25*24*13cm canton
Delivery Time: 3-8 work days
Payment Terms: T/T
Supply Ability: 100000pcs/month
Contact Now
Detailed Product Description
Hardness: 25shore00 KEYWORD: Blue Silicone Rubber Pads
Color: Blue Part Number: TIF100-12U
Material: Silicone
High Light:

Silicone Rubber CPU Thermal Pad

,

25 Shore 00 CPU Thermal Pad

,

1.5 w/mk cpu cooling pad

High performance low cost CPU thermal pad TIF100-12U with blue color for various electronic device

Company Profile

Ziitek Electronic Material and Technology Ltd. provides product solutions to equipment product which generates too much heat affecting its high performance when using. Plus thermal products can control and manage heat to keep it cool to some extent.

The TIF™100-12U  is an electrically isolating material, which allows its use in applications requiring isolation between heat sinks and high-voltage, bare-leaded devices.

Features

Broad range of hardnesses available 1.5 W/mK
Electrically isolating
Outstanding thermal performance




Applications

Mass storage devices
Broad range of hardnesses available
Handheld portable electronics
Audio and video components
Handheld portable electronics
GPS navigation and other portable devices
CD-Rom, DVD-Rom cooling





Typical Properties of TIF 100-12U

Product Name
TIF100-12U Series
Colour
Blue
Construction & Compostion
Ceramic filled silicone rubber
Specific Gravity
2.5 g/cc
Heat Capacity
1 l/g-K
Hardness
25 Shore 00
Tensile Strength
40 psi
Continuos Use Temp
-50 to 200℃
Dielectric Breakdown Voltage
>1500~>5500 VAC
Thermal conductivity
1.5 W/mK
Thickness
0.25mm to 5.0mmT



Standard Thicknesses:
0.010" (0.25mm)  0.020" (0.51mm)  0.030" (0.76mm)  0.040" (1.02mm)  0.050" (1.27mm)  0.060" (1.52mm)      0.070" (1.78mm)  0.080" (2.03mm)  0.090" (2.29mm)  0.100" (2.54mm)  0.110" (2.79mm)  0.120" (3.05mm)      0.130" (3.30mm)  0.140"  (3.56mm) 0.150" (3.81mm)  0.160" (4.06mm)  0.170" (4.32mm)  0.180" (4.57mm)     0.190" (4.83mm) 0.200" (5.08mm)
Consult the factory alternate thickness.


Standard Sheets Sizes:
8" x 16"(203mm x 406mm) 16" x 18"(406mm x 457mm)
TIF™ series Individual die cut shapes can be supplied.


Peressure Sensitive Adhesive:
Request adhesive on one side with "A1" suffix.
Request adhesive on double side with "A2" suffix.


Reinforcement:
TIF™ series sheets type can add with fiberglass reinforced.


High performance low cost CPU thermal pad TIF100-12U with blue color for various electronic device 0

Why Choose us ?



1.Our value message is'' Do it right the First time, total quality control''.

2.Our core competencies is thermal conductive interface materials

3.Competitive advantage products.

4.Condidentiality agreement Bussiness Secrect Contract

5.Free sample offer

6.Quality assurance contract



Q: How do I request customized samples?
A: To request samples, you can leave us message on website, or just contact us by send email or call us.


TIF100-12U Series Datasheet-(E)-REV02-CRM.pdf
